Erdite

NaFeS2 · 2H2O
IMA status
  • Approved
IMA symbol
Erd
Discovered
1980
IMA approved
1978
Also known as
  • Erdiet
  • IMA1977-048

Where it forms, where it's found

Geological setting

In mafic, alkalic diatreme. Very young rock (29 m.y.)

Pegmatites in nepheline syenite

Type locality
Coyote Peak
  1. Humboldt County
  2. California
  3. USA

41.1333°, -123.8589°

7recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Metallic
Transparency
Opaque
Colour
Copper-red

Tarnishes quickly

Streak
Black
Cleavage
Distinct/Good

(110) Good

Density
2.30 g/cm³

Optical

Pleochroism
Strong

Extreme. Brilliant reddish-orange through greenish grays and pinkish grays to dark gray with barely perceptible bluish or greenish tint.

Anisotropism
Strong.
Tropism
Anisotropic
Reflectance R%
(10.2,23.8) 400, (9.8,28.8) 420, (10.1,27.3) 440, (10.9,20.8) 460, (11.3,15.6) 480, (11.3,16.6) 500, (11.0,23.3) 520, (10.6,25.7) 540, (10.3,25.7) 560, (10.0,31.6) 580, (9.8,36.6) 600, (9.7,43.1) 620, (9.8,46.9) 640, (10.0,44.3) 660, (10.6,39.3) 680, (11.0,35.3) 700
Reflected-light panel
10.4 %anisotropic · dual curve
Specimen sRGB 118, 84, 45
White reference100 % reflector under same lamp
R₁ R₂
Mode
Anisotropism
Strong.

Crystallography

Crystal system
Monoclinic
Space group
C2/c
Cell parameters
a = 10.693 Å · b = 9.115 Å · c = 5.507 Å
Cell angles
β = 92.17 °
Ratio a:b:c
1 : 0.852 : 0.515
Z
4
Morphology

Minute fibers, fine bladed crystals to 1 mm long.

Type-locality form

Copper-red granular masses of impure erdite reach dimensions of several millimeters. The largest clean single crystals measure 0.5 x 1 mm.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
16SSulfurSulfur232.06064.120
35.82%
26FeIronIron155.84555.845
31.20%
8OOxygenOxygen215.99931.998
17.88%
11NaSodiumSodium122.99022.990
12.85%
1HHydrogenHydrogen41.0084.032
2.25%
Total178.985100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • K

Synonyms

  • Erdiet
  • IMA1977-048

In other languages

German
Erdit · IMA 1977-048
Italian
Erdite
Chinese
水硫铁钠矿
Russian
Эрдит

Classification

Strunz
10th ed.

2.FD.20

  • 2Sulfides and SulfosaltsClass
  • 2.FSulfides of arsenic, alkalies; sulfides with halide, oxide, hydroxide, H2ODivision
  • 2.FDWith O, OH, H2OGroup
  • 2.FD.20ErditeSpecies
Dana
8th ed.

02.14.05.01

  • 02SulfidesClass
  • 02.14Hydroxysulfides and Hydrated SulfidesType
  • 02.14.05— unnamed intermediate level —Group
  • 02.14.05.01ErditeSpecies
CIM

3.0.1

  • 3Sulphides, Selenides, Tellurides, Arsenides and Bismuthides (except the arsenides, antimonides and bismuthides of Cu, Ag and Au, which are included in Section 1)Class
  • 3.0Sulphides etc. of the alkalisGroup
  • 3.0.1ErditeSpecies

Literature, links & citation

Citations
  1. 1980Czamanske, Gerald K., Leonard, B. F., Clark, Joan R. (1980) Erdite, a new hydrated sodium iron sulfide mineral. American Mineralogist, 65 (5-6) 509-515
  2. 1980Konnert, Judith A., Evans, H. T. (1980) The crystal structure of erdite, NaFeS2·2H2O. American Mineralogist, 65 (5-6) 516-521
  3. 2005(2005) Erdite. Handbook of Mineralogy. Mineralogical Society of America
