Ermeloite

Al(PO4) · H2O
IMA status
  • Approved
IMA symbol
Erm
Also known as
  • Ermeloiet

Where it forms, where it's found

Geological setting

a pegmatite outcropping in granodiorites of the Morrazo peninsula

Type locality
Mount Ermelo
  1. Moaña
  2. Pontevedra
  3. Galicia
  4. Spain

42.2972°, -8.7542°

1recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103.5 – 4/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
light blue to white
Streak
white
Tenacity
brittle
Fracture
Conchoidal
Density
2.923 g/cm³

Optical

UV response
none
Notes

Optical properties could not be measured due to the microgranular nature of the specimen

Crystallography

Crystal system
Monoclinic
Space group
C2/c
Cell parameters
a = 6.5371(4) Å · b = 7.5670(5) Å · c = 7.1146(5) Å
Cell angles
β = 115.335(2) °
Ratio a:b:c
1 : 1.158 : 1.088
Z
4
Type-locality form

short-prismatic crystals with a maximum size of 0.05 mm

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen515.99979.995
57.15%
15PPhosphorusPhosphorus130.97430.974
22.13%
13AlAluminiumAluminium126.98226.982
19.28%
1HHydrogenHydrogen21.0082.016
1.44%
Total139.967100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Ermeloiet

In other languages

German
Ermeloit · IMA 2021-017a

Classification

Strunz
10th ed.

8.CB.05

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.CPhosphates without additional anions, with H2ODivision
  • 8.CBWith only medium-sized cations, RO4:H2O = 1:1Group
  • 8.CB.05ErmeloiteSpecies

Group, growth & confusion

In the same group
7 members

Literature, links & citation

Citations
  1. 2022Miyawaki, Ritsuro, Hatert, Frédéric, Pasero, Marco, Mills, Stuart J. (2022) IMA Commission on New Minerals, Nomenclature and Classification (CNMNC) – Newsletter 68. European Journal of Mineralogy, 34 (5) 385-391 doi:10.5194/ejm-34-385-2022 DOI: 10.5194/ejm-34-385-2022
  2. 2024Vérez, Guillermo Z., Vázquez, Carlos J. Rodríguez, Mariño, Bruno Dacuña, Cereijo, Inés Fernández, del Tánago, José González, Martínez, Ramón Jiménez, Pérez, Ramiro Barreiro, Segurado, Raquel Antón, Fernández, Ezequiel Vázquez, Dopazo, Montse Gómez, et al. (2024) Ermeloite, AlPO4⋅H2O a new phosphate mineral with kieserite-type structure from Galicia, Spain. Mineralogical Magazine, 88 (4). 412-420 doi:10.1180/mgm.2024.33DOI: 10.1180/mgm.2024.33
