Ershovite

K3Na4(Fe,Mn,Ti)2Si8O20(OH,O)4 · 4H2O
IMA status
  • Approved
IMA symbol
Esh
IMA approved
1991
Also known as
  • Ershoviet
  • IMA1991-014

Where it forms, where it's found

Geological setting

Unweathered (subsurface) alkali pegmatites.

Type locality
Rasvumchorr Mt
  1. Murmansk Oblast
  2. Russia

67.6000°, 33.9000°

2recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102 – 3/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Transparency
Translucent
Colour
Olive-green with brownish or yellowish shades
Streak
White
Cleavage
Perfect

(100) and (101)

Fracture
Fibrous
Density
2.75 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 58° · 2V calc = 60°
Refractive index
1.569 – 1.59
Surface relief
Moderate
Principal indices
nα 1.569 · nβ 1.574 · nγ 1.590
Pleochroism
Strong

Z = dark olive green; X = Y = light green or yellow.

Dispersion
medium
UV response
Not fluorescent
Notes

Absorption: Z > Y ~ X.

Michel-Lévy diagramhighlighted lineδ = 0.0210
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]210 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation210 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
#2
Cell parameters
a = 10.24 Å · b = 11.92 Å · c = 5.27 Å
Cell angles
α = 103.49 ° · β = 96.96 ° · γ = 91.94 °
Ratio a:b:c
1 : 1.164 : 0.515
Unit cell volume
620.8 ų
Z
1
Type-locality form

Disseminated elongate grains with a maximum dimension of 10 mm and parallel fibrous aggregates up to 3 cm long.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen3215.999511.968
40.14%
14SiSiliconSilicon828.085224.680
17.62%
19KPotassiumPotassium339.098117.294
9.20%
26FeIronIron255.845111.690
8.76%
25MnManganeseManganese254.938109.876
8.61%
22TiTitaniumTitanium247.86795.734
7.51%
11NaSodiumSodium422.99091.960
7.21%
1HHydrogenHydrogen121.00812.096
0.95%
Total1275.298100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Mg
  • Ca

Synonyms

  • Ershoviet
  • IMA1991-014

In other languages

German
Ershovit · IMA 1991-014
Spanish
Ershovita
Italian
Ershovite
Chinese
艾尔绍夫石
Russian
Ершовит

Classification

Strunz
10th ed.

9.DF.15

  • 9SilicatesClass
  • 9.DInosilicatesDivision
  • 9.DFInosilicates with 2-periodic multiple chainsGroup
  • 9.DF.15ErshoviteSpecies
Dana
8th ed.

66.06.03.01

  • 66Inosilicates Double-width, Unbranched Chains, (w=2)Class
  • 66.06Double-Width Unbranched Chains, W=2 with P=2 non-amphibole configurationType
  • 66.06.03— unnamed intermediate level —Group
  • 66.06.03.01ErshoviteSpecies

Literature, links & citation

Citations
  1. 1991Rastsvetaeva, R.K., Rekhlova, O.Y., Khomyakov, A.P. (1991) Crystal structure of a new mineral Na, K, Fe silicate. Crystallography Reports: 36: 500-503.
  2. 1991Rastsvetaeva, R.K., Rekhlova, O.Y., Khomyakov, A.P. (1991) Crystal structure of a new natural Na,K,Fe-silicate. Kristallografiya: 36: 892-897.
  3. 1993Khomyakov, A. P., Menshikov, Y. P., Rastsvetaeva, R. K., Necheljustov, G. N. (1993) Ershovite Na4K3(Fe,Mn,Ti)2Si8O20(OH)4·4H2O — a new mineral. Zapiski Vserossijskogo Mineralogicheskogo Obshchestva, 122 (1) 116-120
  4. 1994Jambor, John L., Roberts, Andrew C., Vanko, David A. (1994) New Mineral Names. American Mineralogist, 79 (9-10) 1009-1014
  5. 1997Mandarino, Joseph A. (1997) New Minerals 1990-1994. The Mineralogical Record Inc., Tuscon, Arizona. 220pp.
