Euclase

BeAlSiO4(OH)
IMA status
  • Approved
  • Grandfathered
IMA symbol
Ecs
Discovered
1792
Also known as
  • Euclaas
  • Euclasit
  • Euclasita
  • +1 more

Where it forms, where it's found

Geological setting

Decomposition of beryl in pegmatites and alpine veins

Type locality
Ouro Preto
  1. Minas Gerais
  2. Brazil
119recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789107.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Colorless · white · pale green to deep yellowish green · greenish blue · pale blue to deep blue · pink
Streak
White
Tenacity
brittle
Cleavage
Perfect

Perfect on (010). Imperfect on (110), (001).

Fracture
Conchoidal
Density
2.99 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 50° · 2V calc = 48°
Refractive index
1.652 – 1.671
Surface relief
High
Principal indices
nα 1.652 · nβ 1.655 · nγ 1.671
Pleochroism
Visible

Shades of deep blue

Dispersion
none
Extinction
Z ∧ c = 41°.
Michel-Lévy diagramhighlighted lineδ = 0.0190
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]190 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation190 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
#14
Cell parameters
a = 4.763(5) Å · b = 14.29(2) Å · c = 4.618(5) Å
Cell angles
β = 100.25 °
Ratio a:b:c
1 : 3.000 : 0.970
Z
4
Morphology

Prismatic crystals. Forms include (100), (010), (001)(rare), {20·1·0}, {16·1·0}, 910}, (410), (320), (430), (650), (110), {9·10·0}, (670), (340), (230), (590), (120), (130), (104), (102), (101), (011), {0·11·6}, (021), {0·11·4}, (031), (041), (061), (111), (332), (112), (111), (221), (323), {_1_2·3·1}, (211), (124), (121), (141), (155), (151), (231), {_6·10·1}, (593), (121), (131), (142), (162), (152), {_2·13·5}, {_2·13·4}, (173), (182), (197).

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen515.99979.995
55.14%
14SiSiliconSilicon128.08528.085
19.36%
13AlAluminiumAluminium126.98226.982
18.60%
4BeBerylliumBeryllium19.0129.012
6.21%
1HHydrogenHydrogen11.0081.008
0.69%
Total145.082100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Zn
  • F
  • Ca
  • Mg
  • Fe
  • Na

Synonyms

  • Euclaas
  • Euclasit
  • Euclasita
  • Euclasite

In other languages

French
euclase
German
Euklas
Spanish
Euclasa · Euclasita
Italian
Euclasio
Japanese
ユークレース
Chinese
蓝柱石
Russian
хрупик · Эвклаз
Arabic
أوكلاز

Classification

Strunz
10th ed.

9.AE.10

  • 9SilicatesClass
  • 9.ANesosilicatesDivision
  • 9.AENesosilicates with additional anions (O,OH,F,H2O); cations in tetrahedral [4] coordinationGroup
  • 9.AE.10EuclaseSpecies
Dana
8th ed.

52.02.01.01

  • 52Nesosilicates Insular Sio4 Groups and O, Oh, F, H2oClass
  • 52.02Insular SiO4 Groups and O, OH, F, and H2O with cations in [4] and >[4] coordinationType
  • 52.02.01Euclase groupGroup
  • 52.02.01.01EuclaseSpecies
CIM

16.6.2

  • 16Silicates Containing Aluminum and other MetalsClass
  • 16.6Aluminosilicates of BeGroup
  • 16.6.2EuclaseSpecies

Literature, links & citation

Citations
  1. 1792Haüy, R.J. (1792) De l´euclase. Observations sur la Physique, sur l’Histoire Naturelle et sur les Arts: 41: 155-156.
  2. 1842Shepard, C.U. (1842) On Washingtonite (a new Mineral), the discovery of Euclase in Connecticut, and additional notices of the supposed Phenakite of Goshen, and Calstron-baryte of Schoharie, NY. American Journal of Science and Arts: 43(2): 364.
  3. 1853Mallet, J.W. (1853) Analysis of euclase. The London, Edinburgh, and Dublin Philosophical Magazine and Journal of Science: 5(30): 127-127.
  4. 1853Dana, J.D. (1853) On the Isomorphism of Sphene and Euclase. American Journal of Science and Arts: 16(46): 96.
  5. 1882Guyot, M. (1882) Description of a Crystal of Euclase belonging to my Collection. Mineralogical Magazine: 5(23): 107-108.
