Fahleite

CaZn5Fe3+2(AsO4)6 · 14H2O
IMA status
  • Approved
IMA symbol
Fhl
Discovered
1982
IMA approved
1982
Also known as
  • Fahleiet
  • IMA1982-061

Where it forms, where it's found

Geological setting

Oxidation zone

Type locality
Tsumeb Mine (Ongopolo Mine)
  1. Tsumeb
  2. Oshikoto Region
  3. Namibia

-19.2270°, 17.7276°

1recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789102/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Sikly · pearly
Transparency
Transparent
Colour
Yellow · grey · bright-green
Tenacity
sectile
Cleavage
Perfect

⊥ fiber length

Density
3.08 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 39° · 2V calc = 40°
Refractive index
1.628 – 1.656
Surface relief
Moderate
Principal indices
nα 1.628 · nβ 1.631 · nγ 1.656
Dispersion
weak to distinct
Michel-Lévy diagramhighlighted lineδ = 0.0280
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]280 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation280 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Cell parameters
a = 6.4 Å · b = 11.72 Å · c = 21.9 Å
Ratio a:b:c
1 : 1.831 : 3.422
Z
2
Morphology

Crystals are curved and twisted, in fibrous bundles, to about 1.5 cm;

Type-locality form

Crystals are curved and twisted, in fibrous bundles

Comment

point and space groups not determined

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen3815.999607.962
38.86%
33AsArsenicArsenic674.922449.532
28.74%
30ZnZincZinc565.380326.900
20.90%
26FeIronIron255.845111.690
7.14%
20CaCalciumCalcium140.07840.078
2.56%
1HHydrogenHydrogen281.00828.224
1.80%
Total1564.386100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Fahleiet
  • IMA1982-061

In other languages

French
Fahléite
German
Fahleit · IMA 1982-061
Italian
Fahleite

Classification

Strunz
10th ed.

8.CH.55

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.CPhosphates without additional anions, with H2ODivision
  • 8.CHWith large and medium-sized cations, RO4:H2O < 1:1Group
  • 8.CH.55FahleiteSpecies
Dana
8th ed.

40.05.08.02

  • 40Hydrated Normal Phosphates, Arsenates and VanadatesClass
  • 40.05AXO4·xH2OType
  • 40.05.08Smolianinovite GroupGroup
  • 40.05.08.02FahleiteSpecies
CIM

20.3.21

  • 20Arsenates (also arsenates with phosphate, but without other anions)Class
  • 20.3Arsenates of Zn, Cd or HgGroup
  • 20.3.21FahleiteSpecies

Group, growth & confusion

In the same group
1 members

Literature, links & citation

Citations
  1. 1988Medenbach, O., Schmetzer, K., Abraham, K. (1988) Fahleite from Tsumeb/Namibia, a new mineral belonging to the smolianinovite group. Neues Jahrbuch für Mineralogie - Monatshefte, 1988. 167-171
  2. 1989Jambor, John L., Puziewicz, Jacek (1989) New Mineral Names. American Mineralogist, 74 (3-4) 500-504
  3. 2005(2005) Fahleite. Handbook of Mineralogy. Mineralogical Society of America
