Fencooperite

Ba6Fe3+3Si8O23(CO3)2Cl3 · H2O
IMA status
  • Approved
IMA symbol
Fco
IMA approved
2000
Also known as
  • Fencooperiet
  • IMA2000-023

Where it forms, where it's found

Type locality
Trumbull Peak Ba-silicate deposit
  1. Trumbull Peak
  2. Clearing House
  3. Clearing House Mining District
  4. East Belt
  5. Mariposa County
  6. California
  7. USA

37.6919°, -119.8642°

2recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104.5 – 5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Colour
Jet black to a dirty grey-brown (on very thin edges)
Streak
Greyish black
Cleavage
None Observed
Fracture
Irregular/Uneven · Sub-Conchoidal
Density
4.212 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
1.711 – 1.723
Surface relief
High
Principal indices
nω 1.723 · nε 1.711
Pleochroism
Strong

Very strongly pleochroic. <em>n</em><sub>ω</sub> = deep bluish-black <em>n</em><sub>ε</sub> = light greenish-gray

UV response
Not fluorescent.
Notes

Absorption: O>>E.

Michel-Lévy diagramhighlighted lineδ = 0.0120
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]120 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation120 nm
Order1st order
XPL colour

Crystallography

Crystal system
Trigonal
Space group
#84
Cell parameters
a = 10.727 Å · c = 7.085 Å
Unit cell volume
706.1 ų
Morphology

No crystal forms observed.

Twinning

No twinning observed.

Type-locality form

A dominant phase within black aggregates 2 mm across in barium-silicate-rich lenses. Individual grains are anhedral to somewhat rounded to occasionally platy, and do not exceed 100 µm in size.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
56BaBariumBarium6137.327823.962
45.06%
8OOxygenOxygen3015.999479.970
26.25%
14SiSiliconSilicon828.085224.680
12.29%
26FeIronIron355.845167.535
9.16%
17ClChlorineChlorine335.450106.350
5.82%
6CCarbonCarbon212.01124.022
1.31%
1HHydrogenHydrogen21.0082.016
0.11%
Total1828.535100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Fencooperiet
  • IMA2000-023

In other languages

German
Fencooperit · IMA 2000-023
Italian
Fencooperite

Classification

Strunz
10th ed.

9.BH.20

  • 9SilicatesClass
  • 9.BSorosilicatesDivision
  • 9.BHSorosilicates with Si3O10, Si4O11, etc. anions; cations in tetrahedral [4] and greater coordinationGroup
  • 9.BH.20FencooperiteSpecies

Literature, links & citation

Citations
  1. 2001Grice, J.D. (2001) The crystal structure of fencooperite: Unique [Fe33+O13] pinwheels cross-connected by [Si8O22] islands. Canadian Mineralogist: 39: 1065-1071.
  2. 2001Roberts, A. C., Grice, J. D., Dunning, G. E., Venance, K. E. (2001) Fencooperite, Ba6Fe3+3Si8O23(CO3)2Cl3 · H2O, a new mineral species from Trumbull Peak, Mariposa County, California. The Canadian Mineralogist, 39 (4) 1059-1064 doi:10.2113/gscanmin.39.4.1059 DOI: 10.2113/gscanmin.39.4.1059
  3. 2002Jambor, J.L., Roberts, A.C. (2002) New mineral names. American Mineralogist: 87: 765-768.
  4. 2021(2021) Fencooperite. Handbook of Mineralogy. Mineralogical Society of America
