Fergusonite-(Ce)

CeNbO4 · 0.3H2O
IMA status
  • Approved
  • Questionable
IMA symbol
Fgs-Ce
Also known as
  • Fergusoniet-(Ce)
  • β-Fergusonit-(Ce)

Where it forms, where it's found

Geological setting

Carbonatite.

Type locality
Chernigovskiy Massif (Chernigovka Massif
  1. Novopoltavskiy Massif)
  2. Pryazovske Raion
  3. Zaporizhia Oblast
  4. Ukraine

47.2330°, 36.2500°

21recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105.5 – 6.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Colour
Dark red to black
Density
5.48 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
2.2 – 2.3
Surface relief
Very high
Principal indices
nω 2.30 · nε 2.20
Michel-Lévy diagramhighlighted lineδ = 0.1000
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]1000 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation1000 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Tetragonal
Cell parameters
a = 5.17 Å · c = 5.30 Å
Type-locality form

Irregular poikiloblasts to 1 cm and rare prismatic dipyramidal crystals to 1 mm.

Comment

Space group n.d.; on heated material

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
58CeCeriumCerium1140.116140.116
46.33%
41NbNiobiumNiobium192.90692.906
30.72%
8OOxygenOxygen4.315.99968.796
22.75%
1HHydrogenHydrogen0.61.0080.605
0.20%
Total302.423100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Fergusoniet-(Ce)
  • β-Fergusonit-(Ce)

In other languages

German
Fergusonit-(Ce)
Italian
Fergusonite- · Fergusonite-(Ce)
Chinese
褐铈铌矿

Classification

Strunz
10th ed.

7.GA.05

  • 7SulfatesClass
  • 7.GMolybdates, Wolframates and NiobatesDivision
  • 7.GAWithout additional anions or H2OGroup
  • 7.GA.05Fergusonite-(Ce)Species
Dana
8th ed.

08.01.01.03

  • 08Multiple Oxides Containing Niobium, Tantalum or TitaniumClass
  • 08.01ABO4Type
  • 08.01.01Fergusonite Group (Tetragonal)Group
  • 08.01.01.03Fergusonite-(Ce)Species
CIM

18.2.3

  • 18Niobates and TantalatesClass
  • 18.2Niobates and tantalates containing rare earths but not UGroup
  • 18.2.3Fergusonite-(Ce)Species

Group, growth & confusion

Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1976Kapustin, Yu.L. (1976) New occurrence of accessory cerium fergusonite in carbonatites. Trudy Mineral. Muzeya Akad. Nauk SSSR, 25, 166–172. (in Russian)
  2. 1977(1977) Chemical Abstracts, 87, 152.
  3. 1986Kapustin, Yu.L. (1986) Rare-earth mineralization in late carbonatites of the Novopoltavsk Massif. Novye Dannye Mineral., 33, 43-52. (in Russian)
  4. 1987Peishan Zhang and Pejie Tao (1987) Characteristics of the fergusonite- and aeschynite-group minerals in China. Zhongguo Xitu Xuebao, 5(1), 1–7 (in Chinese).
  5. 1987(1987) Chemical Abstracts, 107, 24.
Cite this entry
@misc{mineral2026,
  author    = {Mineral Index editorial board},
  title     = {Fergusonite-(Ce) — Mineral Index},
  year      = {2026},
  url       = {https://mineralindex.org/minerals/fergusonite-ce-1478},
  note      = {Accessed 2026-05-11}
}
