Ferri-obertiite

NaNa2(Mg3Fe3+Ti)Si8O22O2
IMA status
  • Approved
IMA symbol
Fob
IMA approved
2015
Also known as
  • Ferri-obertiiet
  • IMA2015-079

Where it forms, where it's found

Geological setting

In vesicles in pale beige silicate veins within a green-yellow scoria found from a basalt quarry.

Type locality
Rothenberg Quarry
  1. Bell
  2. Mendig
  3. Mayen-Koblenz
  4. Rhineland-Palatinate
  5. Germany

50.4044°, 7.2322°

9recorded occurrences
Source · OpenStreetMap

Physical

Transparency
Transparent
Colour
Pink-orange
Tenacity
brittle
Cleavage
Perfect

Perfect cleavage parallel to (110).

Density
3.145 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 66.4° · 2V calc = 64.7°
Refractive index
1.664 – 1.722
Surface relief
High
Principal indices
nα 1.664 · nβ 1.680 · nγ 1.722
Pleochroism
Visible

X = pale pink; Y = pinkish orange; Z = orange brown.

Extinction
X = b; Y ∧ c = 17.8° (β obtuse); Z ∧ a = 3.5° (in β acute).
UV response
Not fluorescent.
Notes

Absorption: X < Y < Z.

Michel-Lévy diagramhighlighted lineδ = 0.0580
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]580 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation580 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/m
Cell parameters
a = 9.7901(7) Å · b = 17.935(1) Å · c = 5.2892(4) Å
Cell angles
β = 104.142(2) °
Ratio a:b:c
1 : 1.832 : 0.540
Unit cell volume
900.58 ų
Z
2
Type-locality form

Acicular crystals of typical size 40 x 40 x 300 μm.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2415.999383.976
44.95%
14SiSiliconSilicon828.085224.680
26.30%
12MgMagnesiumMagnesium324.30572.915
8.54%
11NaSodiumSodium322.99068.970
8.07%
26FeIronIron155.84555.845
6.54%
22TiTitaniumTitanium147.86747.867
5.60%
Total854.253100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Ferri-obertiiet
  • IMA2015-079

In other languages

German
Ferri-Obertiit · IMA 2015-079
Italian
Ferri-obertiite

Classification

Strunz
10th ed.

9.DE.25

  • 9SilicatesClass
  • 9.DInosilicatesDivision
  • 9.DEInosilicates with 2-periodic double chains, Si4O11; ClinoamphibolesGroup
  • 9.DE.25Ferri-obertiiteSpecies

Group, growth & confusion

In the same group
2 members

Literature, links & citation

Citations
  1. 1992Oberti, Roberta, Ungaretti, Luciano, Cannillo, Elio, Hawthorne, Frank C. (1992) The behaviour of Ti in amphiboles: I. Four- and six-coordinate Ti in richterite. European Journal of Mineralogy, 4 (3) 425-440 doi:10.1127/ejm/4/3/0425DOI: 10.1127/ejm/4/3/0425
  2. 2000Hawthorne, Frank C., Cooper, Mark A., Grice, Joel D., Ottolini, Luisa (2000) A new anhydrous amphibole from the Eifel region, Germany: Description and crystal structure of obertiite, NaNa2(Mg3Fe3+Ti4+)Si8O22O2. American Mineralogist, 85 (1) 236-241 doi:10.2138/am-2000-0124 DOI: 10.2138/am-2000-0124
  3. 2012Oberti, R., Cannillo, E., Toscani, G. (2012) How to name amphiboles after the IMA2012 report: rules of thumb and a new PC program for monoclinic amphiboles. Periodico di Mineralogia: 81: 257-267.
  4. 2012Hawthorne, F. C., Oberti, R., Harlow, G. E., Maresch, W. V., Martin, R. F., Schumacher, J. C., Welch, M. D. (2012) Nomenclature of the amphibole supergroup. American Mineralogist, 97 (11) 2031-2048 doi:10.2138/am.2012.4276 DOI: 10.2138/am.2012.4276
  5. 2015Hålenius, U., Hatert, F., Pasero, M., Mills, S. J. (2015) New minerals and nomenclature modifications approved in 2015, CNMNC Newsletter no 28. Mineralogical Magazine, 79 (7) 1859-1864 doi:10.1180/minmag.2015.079.7.18DOI: 10.1180/minmag.2015.079.7.18
