Ferri-winchite

◻(NaCa)(Mg4Fe3+)Si8O22(OH)2
IMA status
  • Approved
IMA symbol
Fwnc
IMA approved
2004
Also known as
  • Ferri-winchiet
  • Ferriwinchit
  • IMA2004-034
  • +1 more

Where it forms, where it's found

Geological setting

Veins cross-cutting pyroxene fenites.

Type locality
Ilmenogorsky alkaline complex
  1. Ilmen Mountains
  2. Chelyabinsk Oblast
  3. Russia
18recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Black
Streak
Greenish gray
Tenacity
brittle
Cleavage
Distinct/Good

On (110), intersecting at ~56º.

Fracture
Hackly
Density
3.14 g/cm³

Optical

Optical type
Biaxial (-)
Refractive index
1.67 – 1.685
Surface relief
High
Principal indices
nα 1.670 · nβ 1.680 · nγ 1.685
Pleochroism
Visible

Perpendicular to bc plane = bright brownish yellow; Y = lilac; Z = dark blue.

Extinction
Z = b, optic plane ⊥ (010).
Notes

Absorption: c = b > ⊥bc;

Michel-Lévy diagramhighlighted lineδ = 0.0150
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]150 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation150 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/m
Cell parameters
a = 9.811(6) Å · b = 18.014(6) Å · c = 5.295(4) Å
Cell angles
β = 104.1(6) °
Ratio a:b:c
1 : 1.836 : 0.540
Unit cell volume
908 ų
Z
2
Type-locality form

Needle-shaped crystals.

Synonyms

  • Ferri-winchiet
  • Ferriwinchit
  • IMA2004-034
  • Winchite (of Fermor)

In other languages

German
Ferri-Winchit · IMA 2004-034
Italian
ferri-winchite · ferriwinchite

Classification

Strunz
10th ed.

9.DE.20

  • 9SilicatesClass
  • 9.DInosilicatesDivision
  • 9.DEInosilicates with 2-periodic double chains, Si4O11; ClinoamphibolesGroup
  • 9.DE.20Ferri-winchiteSpecies

Group, growth & confusion

In the same group
2 members

Literature, links & citation

Citations
  1. 2001Sokolova, E. V., Hawthorne, F. C., Gorbatova, V., McCammon, C., Schneider, J. (2001) Ferrian winchite from the Ilmen mountains, southern Urals, Russia and some problems with the current scheme for amphibole nomenclature. The Canadian Mineralogist, 39 (1). 171-177 doi:10.2113/gscanmin.39.1.171 DOI: 10.2113/gscanmin.39.1.171
  2. 2005Bazhenov, A.G., Mironov, A.B., Mufiakhov, V.A., Khvorov, P.V. (2005) Ferriwinchite NaCaMg4Fe3+[Si8O22](OH,F)2 — a new mineral of the amphibole group (Ilmenogorsky alkaline complex, the South Urals). Zapiski Rossiiskogo Mineralogicheskogo Obshchetstva, 134(3), 74-77.
  3. 2006Hawthorne, F. C., Oberti, R. (2006) On the classification of amphiboles. The Canadian Mineralogist, 44 (1) 1-21 doi:10.2113/gscanmin.44.1.1DOI: 10.2113/gscanmin.44.1.1
  4. 2006Ercit, T. S.; Piilonen, P.C.; Locock, A.J.; Kolitsch, U.; Rowe, R. (2006) New mineral names. American Mineralogist, 91 (7). 1201-1209 doi:10.2138/am.2006.467DOI: 10.2138/am.2006.467
  5. 2012Hawthorne, F. C., Oberti, R., Harlow, G. E., Maresch, W. V., Martin, R. F., Schumacher, J. C., Welch, M. D. (2012) Nomenclature of the amphibole supergroup. American Mineralogist, 97 (11) 2031-2048 doi:10.2138/am.2012.4276 DOI: 10.2138/am.2012.4276
