Ferro-papikeite

NaFe2+2(Fe2+3Al2)(Si5Al3O22)(OH)2
IMA status
  • Approved
IMA symbol
Fpa
Also known as
  • Ferro-papikeiet
  • IMA2020-021
  • Sodic-ferro-gedrite

Where it forms, where it's found

Geological setting

medium-grade felsic metavolcanic rock, of the lower amphibolite facies

Type locality
Ferro-papikeite type locality
  1. Nordmark mining district
  2. Filipstad
  3. Värmland County
  4. Sweden

59.8439°, 14.1008°

4recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789106/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
pale brown
Streak
colorless to very pale brown
Tenacity
brittle
Cleavage
Perfect

(210); cleavage systems intersecting at ~56°

Fracture
Splintery
Density
3.488 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 86.2° · 2V calc = 88.3°
Refractive index
1.674 – 1.716
Surface relief
High
Principal indices
nα 1.674 · nβ 1.692 · nγ 1.716
Pleochroism
Visible

X= very pale brown Y = Z = honey brown

Dispersion
weak r < v
UV response
none
Michel-Lévy diagramhighlighted lineδ = 0.0420
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]420 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation420 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
Pnma
Cell parameters
a = 18.628(4) Å · b = 17.888(4) Å · c = 5.303(1) Å
Ratio a:b:c
1 : 0.960 : 0.285
Z
4
Type-locality form

subhedral grains, 0.4–3.0 mm in size, and sheaf like aggregates of prismatic crystals

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2415.999383.976
39.85%
26FeIronIron555.845279.225
28.98%
14SiSiliconSilicon528.085140.425
14.57%
13AlAluminiumAluminium526.982134.910
14.00%
11NaSodiumSodium122.99022.990
2.39%
1HHydrogenHydrogen21.0082.016
0.21%
Total963.542100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From Mindat formula

Synonyms

  • Ferro-papikeiet
  • IMA2020-021
  • Sodic-ferro-gedrite

In other languages

German
Ferro-Papikeit · IMA 2020-021
Italian
ferro-papikeite

Classification

Strunz
10th ed.

9.DD.05

  • 9SilicatesClass
  • 9.DInosilicatesDivision
  • 9.DDInosilicates with 2-periodic double chains, Si4O11; OrthoamphibolesGroup
  • 9.DD.05Ferro-papikeiteSpecies

Group, growth & confusion

In the same group
1 members

Literature, links & citation

Citations
  1. 1988Damman, A. (1988) Hydrothermal subsilicic sodium gedrite from the Gåsborn area, West Bergslagen, central Sweden. Mineralogical Magazine, 52 (365) 193-200 doi:10.1180/minmag.1988.052.365.05DOI: 10.1180/minmag.1988.052.365.05
  2. 1996Linthout, Kees, Lustenhouwer, Wim J. (1996) Subsilicic sodium gedrite in leptite of quartz keratophyric origin, Nordmark (Sweden) Mineralogical Magazine, 60 (399) 379-387 doi:10.1180/minmag.1996.060.399.13 DOI: 10.1180/minmag.1996.060.399.13
  3. 2020Miyawaki, Ritsuro, Hatert, Frédéric, Pasero, Marco, Mills, Stuart J. (2020) IMA Commission on New Minerals, Nomenclature and Classification (CNMNC) – Newsletter 56. European Journal of Mineralogy, 32 (4) 443-448 doi:10.5194/ejm-32-443-2020 DOI: 10.5194/ejm-32-443-2020
  4. 2022(2022) Ferro-papikeite. Handbook of Mineralogy. Mineralogical Society of America
  5. 2022Hawthorne, Frank C., Day, Maxwell C., Fayek, Mostafa, Linthout, Kees, Lustenhouwer, Wim. J., Oberti, Roberta (2022) Ferro-papikeite, ideally NaFe22+(Fe32+Al2)(Si5Al3)O22(OH)2, a new orthorhombic amphibole from Nordmark (Western Bergslagen), Sweden: Description and crystal structure. American Mineralogist, 107 (2) 306-312 doi:10.2138/am-2021-7877DOI: 10.2138/am-2021-7877
