Ferrobobfergusonite

◻Na2Fe2+5Fe3+Al(PO4)6
IMA status
  • Approved
IMA symbol
Fbfg
IMA approved
2017
Also known as
  • Ferrobobfergusoniet
  • IMA2017-006

Where it forms, where it's found

Type locality
Victory Mine
  1. Custer
  2. Custer Mining District
  3. Custer County
  4. South Dakota
  5. USA

43.7825°, -103.5692°

1recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
deep green-brown
Streak
pale green-yellow
Tenacity
brittle
Cleavage
Perfect

on (010)

Density
3.68 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 65° · 2V calc = 60°
Refractive index
1.698 – 1.727
Surface relief
High
Principal indices
nα 1.698 · nβ 1.705 · nγ 1.727
Pleochroism

X = yellowish brown, Y = brown, and Z = deep brown

Dispersion
very strong, r > v
Notes

optical axes orientation: α ∧ X = 16°, β = Y

Michel-Lévy diagramhighlighted lineδ = 0.0290
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]290 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation290 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Cell parameters
a = 12.7156(3) Å · b = 12.3808(3) Å · c = 10.9347(3) Å
Cell angles
β = 97.3329(10) °
Ratio a:b:c
1 : 0.974 : 0.860
Twinning

not observed (macroscopically)

Parting
not observed (macroscopically)
Type-locality form

as broken pieces of blocky or tabular habit, where single crystals are up to 0.9 × 0.7 × 0.4 mm in size

Comment

Spacegroup P21/n

Crystal structure

Synonyms

  • Ferrobobfergusoniet
  • IMA2017-006

In other languages

German
Ferrobobfergusonit · IMA 2017-006

Classification

Strunz
10th ed.

8.AC.07

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.APhosphates, etc. without additional anions, without H2ODivision
  • 8.ACWith medium-sized and large cationsGroup
  • 8.AC.07FerrobobfergusoniteSpecies

Group, growth & confusion

In the same group
1 members
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 2017Hålenius, U., Hatert, F., Pasero, M., Mills, S. J. (2017) New minerals and nomenclature modifications approved in 2017, CNMNC Newsletter No 37. Mineralogical Magazine, 81 (3) 737-742 doi:10.1180/minmag.2017.081.039DOI: 10.1180/minmag.2017.081.039
  2. 2021Yang, Hexiong, Yong, Tommy, Downs, Robert T. (2021) Ferrobobfergusonite, □Na2Fe2+5Fe3+Al(PO4)6, a new mineral of the bobfergusonite group from the Victory Mine, Custer County, South Dakota, USA. The Canadian Mineralogist, 59 (3) 617-627 doi:10.3749/canmin.2000064 DOI: 10.3749/canmin.2000064
  3. 2022(2022) Ferrobobfergusonite. Handbook of Mineralogy. Mineralogical Society of America
