Fersmanite

Ca4(Na,Ca)4(Ti,Nb)4(Si2O7)2O8F3
IMA status
  • Approved
  • Grandfathered
IMA symbol
Fsn
Discovered
1929
Also known as
  • Fersmaniet

Where it forms, where it's found

Geological setting

aegirine-rich nepheline pegmatite

Type locality
Vein No. 1 of Labuntsov
  1. Astrophyllite Stream
  2. Eveslogchorr Mt
  3. Murmansk Oblast
  4. Russia
10recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105 – 5.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Dark brown to golden yellow
Streak
white with pale brownish tint
Fracture
Irregular/Uneven
Density
3.44 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 7° · 2V calc = 46°
Refractive index
1.873 – 1.939
Surface relief
Very high
Principal indices
nα 1.873 – 1.886 · nβ 1.914 – 1.930 · nγ 1.914 – 1.939
Dispersion
relatively strong
Michel-Lévy diagramhighlighted lineδ = 0.0470
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]470 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation470 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Cell parameters
a = 7.21 Å · b = 7.21 Å · c = 20.45 Å
Cell angles
α = 95.15 ° · β = 95.6 ° · γ = 89.04 °
Ratio a:b:c
1 : 1.000 : 2.836
Z
4
Twinning

Possibly on (001).

Comment

Class: _1, 1 : Space group P_1, P1

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
41NbNiobiumNiobium492.906371.624
24.83%
8OOxygenOxygen2215.999351.978
23.51%
20CaCalciumCalcium840.078320.624
21.42%
22TiTitaniumTitanium447.867191.468
12.79%
14SiSiliconSilicon428.085112.340
7.50%
11NaSodiumSodium422.99091.960
6.14%
9FFluorineFluorine318.99856.994
3.81%
Total1496.988100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Fersmaniet

In other languages

German
Fersmanit
Italian
Fersmanite
Russian
Ферсманит

Classification

Strunz
10th ed.

9.BE.72

  • 9SilicatesClass
  • 9.BSorosilicatesDivision
  • 9.BESi2O7 groups, with additional anions; cations in octahedral [6] and greater coordinationGroup
  • 9.BE.72FersmaniteSpecies
Dana
8th ed.

56.02.05.03

  • 56Sorosilicates Si2o7 Groups, with Additional O, Oh, F and H2oClass
  • 56.02Si2O7 Groups and O, OH, F, and H2O with cations in [4] and/or >[4] coordinationType
  • 56.02.05Mosandrite and related speciesGroup
  • 56.02.05.03FersmaniteSpecies
CIM

17.8.6

  • 17Silicates Containing other AnionsClass
  • 17.8Silicates with niobate or tantalateGroup
  • 17.8.6FersmaniteSpecies

Literature, links & citation

Citations
  1. Doklady Akademii Nauk SSSR Seriya A, Comptes Rendus de l’Académie des Sciences de l’URSS: 1929: 297-301.
  2. Kristallografiya: 29: 56-59.
  3. 1929Labuncov, A. (1929) La fersmanite - un nouveau minéral des Monts Chibines.
  4. 1931Foshag, W.W. (1931) New mineral names. American Mineralogist: 16: 92-92.
  5. 1977Machin, M. P. (1977) Fersmanite, (Ca,Na)4(Ti,Nb)2Si2O11(F,OH)2: a restudy. The Canadian Mineralogist, 15 (1) 87-91
