Fettelite

[Ag6As2S7][Ag10HgAs2S8]
IMA status
  • Approved
IMA symbol
Ftt
IMA approved
1994
Also known as
  • Fetteliet
  • IMA1994-056
  • Sanguinite

Where it forms, where it's found

Type locality
Glasberg quarry
  1. Nieder-Beerbach
  2. Mühltal
  3. Darmstadt-Dieburg
  4. Darmstadt
  5. Hesse
  6. Germany

49.7972°, 8.6939°

5recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789103.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Sub-metallic to adamantine
Transparency
Opaque
Colour
Dark violet to scarlet
Streak
Vermillion
Tenacity
brittle
Cleavage
Perfect

(001)

Fracture
Irregular/Uneven · Sub-Conchoidal
Density
6.29 g/cm³

Optical

Optical colour
Greyish white
Anisotropism
Weak
Bireflectance
From white to brownish grey
Internal reflections
Red
Tropism
Anisotropic
Reflectance R%
(30.3,31.0,13.8,14.2) 470, (27.6,29.2,12.0,13.1) 546, (26.0,27.6,10.8,11.7) 589, (23.9,24.8,9.6,10.3) 650
Luminescence
none

Crystallography

Crystal system
Monoclinic
Space group
C2
Cell parameters
a = 26.0388(10) Å · b = 15.0651(8) Å · c = 15.5361(8) Å
Cell angles
β = 90.48(1) °
Ratio a:b:c
1 : 0.579 : 0.597
Unit cell volume
6094.2 ų
Z
8
Morphology

Platy.

Twinning

Intimately twinned with six twin domains.

Type-locality form

Clusters consisting of hexagonal flakes up to 10 x 200 μm, and as compact, subparallel aggregates of hexagonal tablets up to 50 μm thick.

Comment

Strong hexagonal pseudosymmetry (a = 15.00, c = 15.46 A).

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
47AgSilverSilver16107.8681725.888
63.76%
16SSulfurSulfur1532.060480.900
17.76%
33AsArsenicArsenic474.922299.688
11.07%
80HgMercuryMercury1200.592200.592
7.41%
Total2707.068100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Fetteliet
  • IMA1994-056
  • Sanguinite

In other languages

German
Fettelit · IMA 1994-056
Spanish
Fettelita · Sanguinita
Italian
Fettelite
Chinese
弗硫砷汞银矿

Classification

Strunz
10th ed.

2.LA.30

  • 2Sulfides and SulfosaltsClass
  • 2.LUnclassified SulfosaltsDivision
  • 2.LAWithout essential PbGroup
  • 2.LA.30FetteliteSpecies
Dana
8th ed.

03.02.10

  • 03SulfosaltsClass
  • 03.02ø = 4Type
  • 03.02.10— unnamed intermediate level —Group
  • 03.02.10FetteliteSpecies

Literature, links & citation

Citations
  1. 1996Wang, N., Paniagua, A. (1996) Fettelite, a new Hg-sulfosalt mineral from Odenwald. Neues Jahrbuch für Mineralogie - Monatshefte, 1996. 313-320
  2. 1997Mandarino, Joseph A. (1997) Abstracts of New Mineral Descriptions. The Mineralogical Record, 28 (2) 141-145
  3. 1997Jambor, J.L., Puziewicz, J., Roberts, A.C. (1997) New mineral names. American Mineralogist: 82: 620-624.
  4. 2009Bindi, L., Keutsch, F.N., Francis, C.A., Menchetti, S. (2009): Fettelite, [Ag6As2S7][Ag10HgAs2S8] from Chanarcillo, Chile: Crystal structure, pseudosymmetry, twinning, and revised chemical formula. American Mineralogist, 94, 609-615.
  5. 2012Bindi, L., Downs, R. T., Spry, P. G., Pinch, W. W., Menchetti, S. (2012) A chemical and structural re-examination of fettelite samples from the type locality, Odenwald, southwest Germany. Mineralogical Magazine, 76 (3) 551-566 doi:10.1180/minmag.2012.076.3.07DOI: 10.1180/minmag.2012.076.3.07
