Finnemanite

Pb5(As3+O3)3Cl
IMA status
  • Approved
  • Grandfathered
IMA symbol
Fnn
Discovered
1923
Also known as
  • Finnemaniet

Where it forms, where it's found

Geological setting

Crevices in hematite in a metamorphosed Fe-Mn ore body.

Type locality
Långban Mine
  1. Långban Ore District
  2. Filipstad
  3. Värmland County
  4. Sweden

59.8554°, 14.2648°

7recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789102.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent · Opaque
Colour
Gray to black · pale olive-green in transmitted light
Cleavage
Distinct/Good

On (1011), distinct

Density
7.265 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
2.2847 – 2.2949
Surface relief
Very high
Principal indices
nω 2.2949 · nε 2.2847
Michel-Lévy diagramhighlighted lineδ = 0.0102
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]102 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation102 nm
Order1st order
XPL colour

Crystallography

Crystal system
Hexagonal
Space group
#108
Cell parameters
a = 10.322 Å · c = 7.055 Å
Z
2
Morphology

Crystals small, distorted, elongated parallel to [0001], exhibiting (1011) and (0001); as crystalline crusts.

Type-locality form

Thin olive-green flakes.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
82PbLeadLead5207.2001036.000
71.93%
33AsArsenicArsenic374.922224.766
15.61%
8OOxygenOxygen915.999143.991
10.00%
17ClChlorineChlorine135.45035.450
2.46%
Total1440.207100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Finnemaniet

In other languages

German
Finnemanit
Italian
Finnemanite
Chinese
菲氯砷铅矿

Classification

Strunz
10th ed.

4.JB.45

  • 4OxidesClass
  • 4.JArsenites, antimonites, bismuthites, sulfites, selenites, tellurites; iodatesDivision
  • 4.JBArsenites, antimonites, bismuthites; with additional anions, without H2OGroup
  • 4.JB.45FinnemaniteSpecies
Dana
8th ed.

46.01.01.01

  • 46Antimonites and Arsenites Containing Hydroxyl or HalogenClass
  • 46.01(AB)m(XO3)pZqType
  • 46.01.01— unnamed intermediate level —Group
  • 46.01.01.01FinnemaniteSpecies
CIM

23.9

  • 23ArsenitesClass
  • 23.9— unnamed intermediate level —Group
  • 23.9FinnemaniteSpecies

Literature, links & citation

Citations
  1. 1923Aminoff, G. (1923) Finnemanit, ett nytt blyarsenit från Långban. Geologiska Föreningen i Stockholm Förhandlingar, 45 (1) 160-163 doi:10.1080/11035892309444549DOI: 10.1080/11035892309444549
  2. 1923Wherry, E.T. (1923). New minerals: new species. American Mineralogist, 8, 230-231.
  3. 1927Aminoff and Parsons (1927). Geologiska Föeningens I Stockholm. Förhandlinger, Stockholm, 49, 438.
  4. 1951Palache, Charles; Berman, Harry; Frondel, Clifford (1951) The System of Mineralogy (7th ed.) Vol. 2 - Halides, Nitrates, Borates, Carbonates, Sulfates, Phosphates, Arsenates, Tungstates, Molybdates, Etc. John Wiley and Sons.
  5. 1957Gabrielson, O. (1957) The crystal structure of finnemanite Pb5Cl(AsO3)3. Arkiv för Mineralogi och Geologi, 2 (1-2). 1-8
Cite this entry
@misc{mineral2026,
  author    = {Mineral Index editorial board},
  title     = {Finnemanite — Mineral Index},
  year      = {2026},
  url       = {https://mineralindex.org/minerals/finnemanite-1551},
  note      = {Accessed 2026-05-11}
}
