Fluoro-cannilloite

CaCa2(Mg4Al)(Si5Al3)O22F2
IMA status
  • Approved
IMA symbol
Fca
IMA approved
1996
Also known as
  • Fluoro-cannilloiet
  • Fluorocannilloit
  • Fluorocannilloita
  • +1 more

Where it forms, where it's found

Geological setting

Marble.

Type locality
Pargas
  1. Southwest Finland
  2. Finland
3recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789106/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Transparency
Translucent
Colour
Grey-green

In transmitted light it is pale grayish green to almost colorless with a cloudy and mottled appearance.

Streak
Grey-white
Tenacity
brittle
Cleavage
Perfect

On (110), intersecting at ~56°.

Density
3.05 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 49°
Refractive index
1.611 – 1.633
Surface relief
Moderate
Principal indices
nα 1.611 · nβ 1.616 · nγ 1.633
Pleochroism
Non-pleochroic
Dispersion
relatively strong; type description gives weak r > v.
Luminescence
Nonfluorescent
UV response
Not fluorescent.
Notes

No discernable differential absorption.

Michel-Lévy diagramhighlighted lineδ = 0.0220
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]220 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation220 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/m
Cell parameters
a = 9.826(4) Å · b = 17.906(9) Å · c = 5.301(3) Å
Cell angles
β = 105.41(4) °
Ratio a:b:c
1 : 1.822 : 0.539
Z
2
Type-locality form

Isolated anhedral grains and small granular aggregates up to 0.15 x 0.15 x 0.20 mm in diameter.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2215.999351.978
41.13%
14SiSiliconSilicon528.085140.425
16.41%
20CaCalciumCalcium340.078120.234
14.05%
13AlAluminiumAluminium426.982107.928
12.61%
12MgMagnesiumMagnesium424.30597.220
11.36%
9FFluorineFluorine218.99837.996
4.44%
Total855.781100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Fluoro-cannilloiet
  • Fluorocannilloit
  • Fluorocannilloita
  • IMA1993-033

In other languages

German
Fluoro-Cannilloit · IMA 1993-033
Italian
fluor-cannilloite · fluoro-cannilloite · fluorocannilloite

Classification

Strunz
10th ed.

9.DE.10

  • 9SilicatesClass
  • 9.DInosilicatesDivision
  • 9.DEInosilicates with 2-periodic double chains, Si4O11; ClinoamphibolesGroup
  • 9.DE.10Fluoro-cannilloiteSpecies

Literature, links & citation

Citations
  1. 1996Hawthorne, Frank C., Oberti, Roberta, Ungaretti, Luciano, Grice, Joel D. (1996) A new hyper-calcic amphibole with Ca at the A site; fluor-cannilloite from Pargas, Finland. American Mineralogist, 81 (7) 995-1002 doi:10.2138/am-1996-7-821 DOI: 10.2138/am-1996-7-821
  2. 1997Mandarino, Joseph A. (1997) Abstracts of New Mineral Descriptions. The Mineralogical Record, 28 (2) 141-145
  3. 1998Mandarino, Joseph A. (1998) The Second List of Additions and Corrections to the Glossary of Mineral Species (1995) - The Amphibole Group. The Mineralogical Record, 29 (3) 169-174
  4. 2012Hawthorne, F. C., Oberti, R., Harlow, G. E., Maresch, W. V., Martin, R. F., Schumacher, J. C., Welch, M. D. (2012) Nomenclature of the amphibole supergroup. American Mineralogist, 97 (11) 2031-2048 doi:10.2138/am.2012.4276 DOI: 10.2138/am.2012.4276
