Fluoro-richterite

Na(NaCa)Mg5Si8O22F2
IMA status
  • Approved
IMA symbol
Flrct
IMA approved
1994
Also known as
  • Fluoro-richteriet
  • Fluororichterit
  • Fluorrichterite
  • +1 more

Where it forms, where it's found

Geological setting

In an alkaline complex, where it is a rock-forming component in fenites, carbonatites, and metasomatic rocks.

Type locality
Pit No. 97
  1. Miass
  2. Chelyabinsk Oblast
  3. Russia

55.0167°, 60.1833°

23recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105 – 6/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Transparency
Transparent
Colour
Brown to brownish-red · rose-red · yellow · grey-brown · also pale to dark green.
Streak
white
Tenacity
brittle
Cleavage
Perfect

Perfect on (110)

Fracture
Splintery
Density
3.174 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 71 – 72°
Refractive index
1.612 – 1.629
Surface relief
Moderate
Principal indices
nα 1.612 – 1.618 · nβ 1.621 · nγ 1.627 – 1.629
Pleochroism
Strong

X = light brown to colorless, Y = brownish green to lilac violet, Z = bluish green.

Dispersion
r < v.
Extinction
Optic axial plane [010], positive elongation, c ∧ Z: 18-26°.
Luminescence
Nonfluorescent
Notes

Anomalous interference colors (indigo blue and brown). Absorption: Z > Y > X.

Michel-Lévy diagramhighlighted lineδ = 0.0130
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]130 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation130 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/m
Cell parameters
a = 9.763 Å · b = 17.89 Å · c = 5.122 Å
Cell angles
β = 102.25 °
Ratio a:b:c
1 : 1.832 : 0.525
Z
2
Morphology

Crystals are elongate [001], with well-developed (100) and (010), and less common (110).

Type-locality form

Crystals are elongate [001] to 10 cm, with well-developed (100) and (010), and less common (110).

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2215.999351.978
42.81%
14SiSiliconSilicon828.085224.680
27.33%
12MgMagnesiumMagnesium524.305121.525
14.78%
11NaSodiumSodium222.99045.980
5.59%
20CaCalciumCalcium140.07840.078
4.87%
9FFluorineFluorine218.99837.996
4.62%
Total822.237100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Fluoro-richteriet
  • Fluororichterit
  • Fluorrichterite
  • IMA1992-020

In other languages

German
Fluoro-Richterit · IMA 1992-020
Spanish
Fluororrichterita
Italian
fluoro-richterite · fluororichterite · fluorrichterite

Classification

Strunz
10th ed.

9.DE.20

  • 9SilicatesClass
  • 9.DInosilicatesDivision
  • 9.DEInosilicates with 2-periodic double chains, Si4O11; ClinoamphibolesGroup
  • 9.DE.20Fluoro-richteriteSpecies

Group, growth & confusion

In the same group
4 members

Literature, links & citation

Citations
  1. Mineralogical Abstracts: 94M/3560.
  2. 1865Breithaupt, August (1865) Mineralogische Studien. 25. Richterit, in Mineralogischen Studien. Berg- und hüttenmännische Zeitung, 364
  3. 1955Kohn, J. A.; Comeforo, J. E. (1955) Synthetic asbestos investigations, II: X-ray and other data on synthetic fluor-richterite, -edenite, and boron edenite. American Mineralogist, 40 (5-6). 410-421
  4. 1992Oberti, Roberta, Ungaretti, Luciano, Cannillo, Elio, Hawthorne, Frank C. (1992) The behaviour of Ti in amphiboles: I. Four- and six-coordinate Ti in richterite. European Journal of Mineralogy, 4 (3) 425-440 doi:10.1127/ejm/4/3/0425DOI: 10.1127/ejm/4/3/0425
  5. 1993Bazhenov, A.G., Nedosekova, I.L., Petersen, E.U. (1993). Fluorrichterite, Na2Ca(Mg,Fe)5[Si8O22](F,OH)2; a new mineral species in the amphibole group. Zapiski Vserossiyskogo Mineralogicheskogo Obshchestva, 122(3), 98-102.
