Flurlite

Zn2+Zn2+3Fe3+(PO4)3(OH)2(H2O)7 · 2H2O
IMA status
  • Approved
IMA symbol
Flu
IMA approved
2014
Also known as
  • Flurliet
  • IMA2014-064

Where it forms, where it's found

Geological setting

Zoned granitic phosphate pegmatite.

Type locality
Hagendorf South Pegmatite
  1. Hagendorf
  2. Waidhaus
  3. Neustadt an der Waldnaab District
  4. Upper Palatinate
  5. Bavaria
  6. Germany

49.6503°, 12.4597°

1recorded occurrences
Source · OpenStreetMap

Physical

Transparency
Translucent
Colour
Bright orange red to dark maroon red
Streak
Buff
Tenacity
brittle
Cleavage
Perfect

Parallel to (001).

Fracture
Irregular/Uneven
Density
2.89 g/cm³

Optical

Optical type
Biaxial (-) · 2V calc = 74°
Refractive index
1.6 – 1.68
Surface relief
Moderate
Principal indices
nα 1.60 · nβ 1.65 · nγ 1.68
Pleochroism
Weak

With colours: X = pale yellow, Y = pale orange, Z = orange brown

Dispersion
Weak
Extinction
Parallel. X ≈ c, Y ≈ a, Z ≈ b.
Michel-Lévy diagramhighlighted lineδ = 0.0800
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]800 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation800 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P21/m
Cell parameters
a = 6.3894(8) Å · b = 11.037(1) Å · c = 13.063(2) Å
Cell angles
β = 99.37(2) °
Ratio a:b:c
1 : 1.727 : 2.044
Z
2
Morphology

Platelets forming twisted accordion-like aggregates.

Type-locality form

As ultrathin (<1 μm) translucent platelets that form characteristic twisted accordion-like aggregates, on mitridatite.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2315.999367.977
46.09%
30ZnZincZinc465.380261.520
32.75%
15PPhosphorusPhosphorus330.97492.922
11.64%
26FeIronIron155.84555.845
6.99%
1HHydrogenHydrogen201.00820.160
2.53%
Total798.424100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Flurliet
  • IMA2014-064

In other languages

German
Flurlit · IMA 2014-064
Italian
flurlite

Classification

Strunz
10th ed.

8.DB.40

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.DPhosphates, etc. with additional anions, with H2ODivision
  • 8.DBWith only medium-sized cations, (OH, etc.):RO4< 1:1Group
  • 8.DB.40FlurliteSpecies

Literature, links & citation

Citations
  1. 2015Williams, P. A., Hatert, F., Pasero, M., Mills, S. J. (2015) New minerals and nomenclature modifications approved in 2014 and 2015. Newsletter No 23. Mineralogical Magazine, 79 (1) 51-58 doi:10.1180/minmag.2015.079.1.05DOI: 10.1180/minmag.2015.079.1.05
  2. 2015Grey, I. E., Keck, E., Mumme, W. G., Pring, A., Macrae, C. M., Gable, R. W., Price, J. R. (2015) Flurlite, Zn3Mn2+Fe3+(PO4)3(OH)2·9H2O, a new mineral from the Hagendorf Süd pegmatite, Bavaria, with a schoonerite-related structure. Mineralogical Magazine, 79 (5) 1175-1184 doi:10.1180/minmag.2015.079.5.11 DOI: 10.1180/minmag.2015.079.5.11
  3. 2016Belakovskiy, Dmitriy I.; Cámara, Fernando (2016) New Mineral Names. American Mineralogist, 101 (8). 1920-1924 doi:10.2138/am-2016-nmn101815DOI: 10.2138/am-2016-nmn101815
  4. 2021(2021) Flurlite. Handbook of Mineralogy. Mineralogical Society of America
