Foggite

CaAl(PO4)(OH)2 · H2O
IMA status
  • Approved
IMA symbol
Fgg
Discovered
1973
IMA approved
1973
Also known as
  • Foggiet
  • IMA1973-067

Where it forms, where it's found

Geological setting

Complex granite pegmatite

Type locality
Palermo No. 1 Mine
  1. Groton
  2. Grafton County
  3. New Hampshire
  4. USA

43.7513°, -71.8896°

7recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Colorless to snow-white
Streak
White
Cleavage
Perfect

(010), perfect; (100), good.

Density
2.78 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 40 – 45°
Refractive index
1.61 – 1.611
Surface relief
Moderate
Principal indices
nα 1.610 · nβ 1.610 · nγ 1.611
Dispersion
relatively strong
Michel-Lévy diagramhighlighted lineδ = 0.0010
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]10 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation10 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Cell parameters
a = 9.270(2) Å · b = 21.324(7) Å · c = 5.190(2) Å
Ratio a:b:c
1 : 2.300 : 0.560
Z
8
Morphology

Type material: Forms include c(001), b(010), and a(100). The crystals are thin tabular parallel to b(010), slightly elongated parallel to [001], and are ten to twenty times as broad as they are thick.

Type-locality form

Snow-white balls and radial platy aggregates, visually similar to stilbite.

Comment

Space Group: A2122

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen715.999111.993
52.32%
20CaCalciumCalcium140.07840.078
18.72%
15PPhosphorusPhosphorus130.97430.974
14.47%
13AlAluminiumAluminium126.98226.982
12.61%
1HHydrogenHydrogen41.0084.032
1.88%
Total214.059100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Foggiet
  • IMA1973-067

In other languages

German
Foggit · IMA 1973-067
Italian
Foggite

Classification

Strunz
10th ed.

8.DL.05

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.DPhosphates, etc. with additional anions, with H2ODivision
  • 8.DLWith large and medium-sized cations, (OH, etc.):RO4 = 2:1Group
  • 8.DL.05FoggiteSpecies
Dana
8th ed.

42.07.02.01

  • 42Hydrated Phosphates, Etc.containing Hydroxyl or HalogenClass
  • 42.07(AB)2(XO4)Zq·xH2OType
  • 42.07.02Foggite GroupGroup
  • 42.07.02.01FoggiteSpecies
CIM

19.8.14

  • 19PhosphatesClass
  • 19.8Phosphates of Al and other metalsGroup
  • 19.8.14FoggiteSpecies

Literature, links & citation

Citations
  1. 1975Moore, Paul B., Irving, Anthony J., Kampf, Anthony R. (1975) Foggite, CaAl(OH)2(H2O)[PO4]; goedkenite, (Sr,Ca)2Al(OH)[PO4]2; and samuelsonite, (Ca,Ba)Fe2+2Mn2+2Ca8Al2(OH)2[PO4]10: Three new species from the Palermo No. I pegmatite, North Groton, New Hampshire. American Mineralogist, 60 (11-12) 957-964
  2. 1975Moore, Paul B., Kampf, Anthony R., Araki, Takaharu (1975) Foggite, Ca(H2O)2[CaAl2(OH)4(PO4)2]: Its atomic arrangement and relationship to calcium Tschermak's pyroxene. American Mineralogist, 60 (11-12) 965-971
  3. 2005(2005) Foggite. Handbook of Mineralogy. Mineralogical Society of America
  4. 2005Onac, B. P., Ettinger, K., Kearns, J., Balasz, I. I. (2005) A modern, guano-related occurrence of foggite, CaAl(PO4)(OH)2 · H2O and churchite-(Y), YPO4 · 2H2O in Cioclovina Cave, Romania. Mineralogy and Petrology, 85 (3-4). 291-302 doi:10.1007/s00710-005-0106-4DOI: 10.1007/s00710-005-0106-4
