Fontarnauite

(Na,K)2(Sr,Ca)(SO4)[B5O8(OH)](H2O)2
IMA status
  • Approved
IMA symbol
Fon
Discovered
2009
IMA approved
2014
Also known as
  • Fontarnauiet
  • IMA2009-096a

Where it forms, where it's found

Geological setting

Evaporite basin.

An early diagenetic phase, replacing both probertite and glauberite.

Type locality
Doğanlar boreholes no. 2 and no. 188 (Kütahya-Emet 2 and 188)
  1. Doğanlar village
  2. Emet District
  3. Kütahya Province
  4. Turkey

39.2833°, 29.2185°

1recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102.5 – 3/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Colorless to light brown
Streak
White
Tenacity
brittle
Cleavage
Perfect

(010)

Fracture
Splintery
Density
2.37 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 46° · 2V calc = 46°
Refractive index
1.517 – 1.543
Surface relief
Moderate
Principal indices
nα 1.517 · nβ 1.539 · nγ 1.543
Dispersion
r > v, medium to weak
UV response
Not fluorescent
Michel-Lévy diagramhighlighted lineδ = 0.0260
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]260 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation260 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P21/c
Cell parameters
a = 6.458(2) Å · b = 22.299(7) Å · c = 8.571(2) Å
Cell angles
β = 103.05(1) °
Ratio a:b:c
1 : 3.453 : 1.327
Z
4
Type-locality form

Isolated colorless to light-brown prismatic crystals or as clusters of crystals less than 5 mm long.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1515.999239.985
41.16%
38SrStrontiumStrontium187.62087.620
15.03%
19KPotassiumPotassium239.09878.196
13.41%
5BBoronBoron510.81054.050
9.27%
11NaSodiumSodium222.99045.980
7.89%
20CaCalciumCalcium140.07840.078
6.87%
16SSulfurSulfur132.06032.060
5.50%
1HHydrogenHydrogen51.0085.040
0.87%
Total583.009100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Fontarnauiet
  • IMA2009-096a

In other languages

German
Fontarnauit · IMA 2009-096a
Spanish
Fontarnauita
Italian
fontarnauite
Chinese
枫硼石

Classification

Strunz
10th ed.

6.DA.60

  • 6BoratesClass
  • 6.DTetraboratesDivision
  • 6.DANeso-tetraboratesGroup
  • 6.DA.60FontarnauiteSpecies
Dana
8th ed.

27.01.13

  • 27Compound BoratesClass
  • 27.01MiscellaneousType
  • 27.01.13— unnamed intermediate level —Group
  • 27.01.13FontarnauiteSpecies

Literature, links & citation

Citations
  1. 2010García-Veigas, J., Rosell, L., Alcobé, X., Subias, I., Ortí, F., Gündogan, I., Helvaci, C. (2010) Fontarnauite, a New Sulphate-Borate Mineral from the Emet Borate District (Turkey). Macla, 13, 97-98. [http://www.ehu.es/sem/macla_pdf/macla13/Macla13_097.pdf]
  2. 2014Williams, P. A., Hatert, F., Pasero, M., Mills, S. J. (2014) IMA Commission on New Minerals, Nomenclature and Classification (CNMNC), CNMNC Newsletter No. 22. Mineralogical Magazine, 78 (5) 1241-1248 doi:10.1180/minmag.2014.078.5.10DOI: 10.1180/minmag.2014.078.5.10
  3. 2015www.scinexx.de (2015) http://www.scinexx.de/wissen-aktuell-18530-2015-02-04.html
  4. 2015Cooper, Mark A., Hawthorne, Frank C., García-Veigas, Javier, Alcobé, Xavier, Helvaci, Cahit, Grew, Edward S., Ball, Neil A. (2015) Fontarnauite, (Na,K)2(Sr,Ca)(SO4)[B5O8(OH)](H2O)2, A New Sulfate-Borate Mineral From Doğanlar (Emet), Kütahya Province, Western Anatolia, Turkey. The Canadian Mineralogist, 53 (5) 803-820 doi:10.3749/canmin.1400088DOI: 10.3749/canmin.1400088
  5. 2017(2017) Fontarnauite. Handbook of Mineralogy. Mineralogical Society of America
