Friedrichite

Cu5Pb5Bi7S18
IMA status
  • Approved
IMA symbol
Frd
Discovered
1977
IMA approved
1977
Also known as
  • IMA1977-031

Where it forms, where it's found

Geological setting

From quartz vein found on a scree slope. Surrounding rocks are metamorphic. Schists and gneisses. Emeralds are also found in the area.

Type locality
Sedl
  1. Nasenkopf mountain
  2. Bramberg am Wildkogel
  3. Zell am See District
  4. Salzburg
  5. Austria

47.1994°, 12.3639°

52recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789103.5 – 4/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
Silver-grey
Density
6.98 g/cm³

Optical

Optical colour
Creamy yellow whitish in air, in oil more pinkish
Anisotropism
Strong in oil, distinct in air
Tropism
Anisotropic
Reflectance R%
(41.0,46.7) 470, (40.1,46.2) 546, (39.9,45.8) 589, (39.9,45.6) 650
Reflected-light panel
40.2 %anisotropic · dual curve
Specimen sRGB 225, 157, 88
White reference100 % reflector under same lamp
R₁ R₂
Mode
Anisotropism
Strong in oil, distinct in air
Reflected colour
Creamy yellow whitish in air, in oil more pinkish

Crystallography

Crystal system
Orthorhombic
Cell parameters
a = 33.84(6) Å · b = 11.65(7) Å · c = 4.01(3) Å
Ratio a:b:c
1 : 0.344 : 0.118
Z
2
Morphology

Isolated columnar crystals, granular aggregates

Type-locality form

Isolated crystals or, more commonly, as aggregates of granular shaped to column-like crystals, 0.2 to more than 1.5 mm in size.

Comment

Space Group: P b21m.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
83BiBismuthBismuth7208.9801462.860
43.11%
82PbLeadLead5207.2001036.000
30.53%
16SSulfurSulfur1832.060577.080
17.00%
29CuCopperCopper563.546317.730
9.36%
Total3393.670100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1977-031

In other languages

German
Friedrichit · IMA 1977-031
Italian
Friedrichite
Chinese
弗硫铋铅铜矿

Classification

Strunz
10th ed.

2.HB.05a

  • 2Sulfides and SulfosaltsClass
  • 2.HSulfosalts of SnS archetypeDivision
  • 2.HBWith Cu, Ag, Fe, Sn and PbGroup
  • 2.HB.05aFriedrichiteSpecies
Dana
8th ed.

03.04.05.05

  • 03SulfosaltsClass
  • 03.04ø = 3Type
  • 03.04.05Aikinite Group (Orthorhombic containing Pb, Cu, Bi, & S)Group
  • 03.04.05.05FriedrichiteSpecies
CIM

5.7.8

  • 5Sulphosalts - Sulpharsenites and Sulphobismuthites (those containing Sn, Ge,or V are in Section 6)Class
  • 5.7Sulpharsenites etc. of Pb and other metalsGroup
  • 5.7.8FriedrichiteSpecies

Literature, links & citation

Citations
  1. 1978Chen, T.T., Kirchner, E., and Paar, W. (1978) Friedrichite, Cu5Pb5Bi7S18, a new member of the aikinite-bismuthinite series. Canadian Mineralogist: 16: 127-130.
  2. 1979Fleischer, Michael, Chao, George Y., Mandarino, J. A. (1979) New mineral names. American Mineralogist, 64 (5-6) 652-659
  3. 1998Shimizu, M., Kato, A., Cioflica, G., Lupulescu, M., Shimizu, M. (1998) Friedrichite from Băiţa Bihor, Romania. The Canadian Mineralogist, 36 (3) 861-868
  4. 2002Topa, Dan, Makovicky, Emil, Paar, Werner H. (2002) Composition ranges and exsolution pairs for the members of the bismuthinite-aikinite series from Felbertal, Austria. The Canadian Mineralogist, 40 (3) 849-869 doi:10.2113/gscanmin.40.3.849 DOI: 10.2113/gscanmin.40.3.849
  5. 2005(2005) Friedrichite. Handbook of Mineralogy. Mineralogical Society of America
