Froodite

PdBi2
IMA status
  • Approved
  • Grandfathered
IMA symbol
Fro
Discovered
1958
Also known as
  • Froodiet

Where it forms, where it's found

Geological setting

Sudbury intrusive

Type locality
Frood Mine
  1. McKim Township
  2. Greater Sudbury
  3. Ontario
  4. Canada

46.5339°, -80.9985°

77recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
Grey
Streak
Black
Tenacity
brittle
Cleavage
Perfect

Perfect on (100) less perfect on (001)

Fracture
Irregular/Uneven
Density
12.05 g/cm³

Optical

Optical colour
Creamy white
Anisotropism
Light and dark grays
Tropism
Anisotropic
Reflectance R%
(50.7,52.9) 420, (51.9,54.3) 440, (53.1,55.5) 460, (54.3,56.4) 480, (55.2,57.2) 500, (55.7,57.8) 520, (56.1,58.4) 540, (56.5,59.0) 560, (56.9,59.6) 580, (57.4,60.2) 600, (57.7,60.7) 620, (58.0,61.1) 640, (58.5,61.4) 660, (58.8,62.0) 680, (59.3,63.0) 700
Reflected-light panel
56.0 %anisotropic · dual curve
Specimen sRGB 255, 183, 98
White reference100 % reflector under same lamp
R₁ R₂
Mode
Anisotropism
Light and dark grays
Reflected colour
Creamy white

Crystallography

Crystal system
Monoclinic
Space group
C2/m
Cell parameters
a = 12.74 Å · b = 4.29 Å · c = 5.71 Å
Cell angles
β = 102.52 °
Ratio a:b:c
1 : 0.337 : 0.448
Z
4
Morphology

Rounded grains

Twinning

Sometimes

Type-locality form

Flat cleavage fragments and rounded grains

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
83BiBismuthBismuth2208.980417.960
79.71%
46PdPalladiumPalladium1106.420106.420
20.29%
Total524.380100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Te

Synonyms

  • Froodiet

In other languages

German
Froodit
Italian
froodite

Classification

Strunz
10th ed.

2.AC.45a

  • 2Sulfides and SulfosaltsClass
  • 2.AAlloysDivision
  • 2.ACAlloys of metalloids with PGEGroup
  • 2.AC.45aFrooditeSpecies
Dana
8th ed.

02.12.15.01

  • 02SulfidesClass
  • 02.12AmBnXp, with (m+n):p = 1:2Type
  • 02.12.15— unnamed intermediate level —Group
  • 02.12.15.01FrooditeSpecies
CIM

3.12.41

  • 3Sulphides, Selenides, Tellurides, Arsenides and Bismuthides (except the arsenides, antimonides and bismuthides of Cu, Ag and Au, which are included in Section 1)Class
  • 3.12Sulphides etc. of the platinum metalsGroup
  • 3.12.41FrooditeSpecies

Literature, links & citation

Citations
  1. 1958Hawley, James Edwin; Berry, Leonard Gascoigne (1958) Michenerite and froodite, palladium bismuthide minerals [Ontario]. The Canadian Mineralogist, 6 (2). 200-209
  2. 1973Cabri, L.J., Harris, D.C., and Gait, R.I. (1973) Michenerite (PdBiTe) redefined and froodite (PdBi2) confirmed from the Sudbury area. The Canadian Mineralogist: 11: 903-912.
  3. 1996Evstigneeva, Tatiana, Tarkian, Mahmud (1996) Synthesis of platinum-group minerals under hydrothermal conditions. European Journal of Mineralogy, 8 (3) 549-564 doi:10.1127/ejm/8/3/0549DOI: 10.1127/ejm/8/3/0549
  4. 1998Vavřín, I., Frýda, J. (1998) Michenerite PdBiTe and froodite PdBi2 from the Cu-Ni mineralization in the Ransko massif, Czech Republic. Mineralogy and Petrology, 63 (1) 141-146 doi:10.1007/bf01162772DOI: 10.1007/bf01162772
  5. 2005(2005) Froodite. Handbook of Mineralogy. Mineralogical Society of America
