Garavellite

FeSbBiS4
IMA status
  • Approved
IMA symbol
Grv
Discovered
1979
IMA approved
1978
Also known as
  • Garavelliet
  • IMA1978-018

Where it forms, where it's found

Geological setting

Hydrothermal copper deposit.

Type locality
Frigido Mine
  1. Massa
  2. Massa-Carrara Province
  3. Tuscany
  4. Italy

44.0459°, 10.1503°

9recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Density
5.64 g/cm³

Optical

Pleochroism
Visible
Optical colour
Gray with olive-brown tint
Anisotropism
Strong, yellowish green to bluish gray
Bireflectance
Distinct
Tropism
Anisotropic
Reflectance R%
(34.1,41.7) 470, (33.8,41.1) 546, (33.2,40.2) 589, (33.5,39.7) 650
Reflected-light panel
33.7 %anisotropic · dual curve
Specimen sRGB 207, 145, 81
White reference100 % reflector under same lamp
R₁ R₂
Mode
Bireflectance
Distinct
Anisotropism
Strong, yellowish green to bluish gray
Reflected colour
Gray with olive-brown tint

Crystallography

Crystal system
Orthorhombic
Cell parameters
a = 11.439 Å · b = 14.093 Å · c = 3.754 Å
Ratio a:b:c
1 : 1.232 : 0.328
Z
4
Morphology

Small aggregates of 200 microns.

Type-locality form

Small aggregates, up to 200 µm across, of anhedral crystals.

Comment

Point Group: n.d.; Space Group: n.d.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
83BiBismuthBismuth1208.980208.980
40.59%
16SSulfurSulfur432.060128.240
24.91%
51SbAntimonyAntimony1121.760121.760
23.65%
26FeIronIron155.84555.845
10.85%
Total514.825100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Cu
  • As

Synonyms

  • Garavelliet
  • IMA1978-018

In other languages

German
Garavellit · IMA 1978-018
Italian
Garavellite
Chinese
硫锑铋铁矿

Classification

Strunz
10th ed.

2.HA.20

  • 2Sulfides and SulfosaltsClass
  • 2.HSulfosalts of SnS archetypeDivision
  • 2.HAWith Cu, Ag, Fe (without Pb)Group
  • 2.HA.20GaravelliteSpecies
Dana
8th ed.

03.07.09.04

  • 03SulfosaltsClass
  • 03.07ø = 2Type
  • 03.07.09Galenobismutite GroupGroup
  • 03.07.09.04GaravelliteSpecies
CIM

5.8.7

  • 5Sulphosalts - Sulpharsenites and Sulphobismuthites (those containing Sn, Ge,or V are in Section 6)Class
  • 5.8Sulpharsenites etc. of Mn, Fe, Co and NiGroup
  • 5.8.7GaravelliteSpecies

Group, growth & confusion

In the same group
2 members

Literature, links & citation

Citations
  1. 1979Fleischer, Michael, Burns, Roger G., Cabri, Louis J., Chao, George Y., Hogarth, D. D., Pabst, Adolf (1979) New Mineral Names. American Mineralogist, 64 (11-12) 1329-1334
  2. 1979Gregorio, F., Lattanzi, P., Tanelli, G., Vurro, F. (1979) Garavellite, FeSbBiS4, a new mineral from the Cu-Fe deposit of Valle del Frigido in the Apuane Alps, northern Tuscany, Italy. Mineralogical Magazine, 43 (325) 99-102 doi:10.1180/minmag.1979.043.325.05 DOI: 10.1180/minmag.1979.043.325.05
  3. 1985Wei, B., Li, S., Yin, Z., Geng, M. (1985) The discovery of the native bismuth-antimony system minerals and garavellite. Shaanxi Dizhi (Geology of Shaanxi): 3: 31-37.
  4. 2000Uher, Pavel, Michal, Silvio, Vitálos, Jirí (2000) The Pezinok Antimony Mine, Malé Karpaty Mountains, Slovakia. The Mineralogical Record, 31 (2) 153-162
  5. 2005(2005) Garavellite. Handbook of Mineralogy. Mineralogical Society of America
