Garpenbergite

Mn6AsSbO10(OH)2
IMA status
  • Approved
IMA symbol
Gpb
Also known as
  • Garpenbergiet
  • IMA2020-099

Where it forms, where it's found

Type locality
Garpenberg Norra Mine
  1. Garpenberg
  2. Hedemora
  3. Dalarna County
  4. Sweden

60.3325°, 16.2278°

2recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789105/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Blackish to greyish brown

Translucent in thin splinters.

Streak
Light brown
Tenacity
brittle
Cleavage
Distinct/Good

On (010)

Fracture
Irregular/Uneven · Sub-Conchoidal
Density
4.47 g/cm³

Optical

Pleochroism
Not Visible
Optical colour
Gray
Anisotropism
Weak to moderate.
Bireflectance
None observed.
Tropism
Anisotropic
Reflectance R%
(8.93,9.50) 400, (8.83,9.41) 420, (8.73,9.30) 440, (8.68,9.23) 460, (8.67,9.20) 470, (8.66,9.17) 480, (8.65,9.17) 500, (8.54,9.04) 520, (8.50,9.05) 540, (8.49,9.04) 546, (8.49,9.02) 560, (8.50,8.97) 580, (8.47,8.96) 589, (8.44,8.96) 600, (8.44,8.93) 620, (8.47,8.88) 640, (8.48,8.90) 650, (8.48,8.93) 660, (8.46,8.91) 680, (8.46,8.90) 700
UV response
Not fluorescent.
Notes

Overall refractive index (n) is calculated to 1.847, using Gladstone-Dale constants.

Reflected-light panel
8.6 %anisotropic · dual curve
Specimen sRGB 111, 76, 40
White reference100 % reflector under same lamp
R₁ R₂
Mode
Bireflectance
None observed.
Anisotropism
Weak to moderate.
Reflected colour
Gray

Crystallography

Crystal system
Orthorhombic
Cell parameters
a = 8.6790(9) Å · b = 18.906(2) Å · c = 6.1066 Å
Ratio a:b:c
1 : 2.178 : 0.704
Morphology

Short-prismatic.

Type-locality form

Heavily fractured, short-prismatic and mostly subhedral crystals up to 1.5 mm in length.

Comment

The space group is Ibbm.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
25MnManganeseManganese654.938329.628
45.76%
8OOxygenOxygen1215.999191.988
26.65%
51SbAntimonyAntimony1121.760121.760
16.91%
33AsArsenicArsenic174.92274.922
10.40%
1HHydrogenHydrogen21.0082.016
0.28%
Total720.314100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Garpenbergiet
  • IMA2020-099

In other languages

German
Garpenbergit · IMA 2020-099

Classification

Strunz
10th ed.

4.BB

  • 4OxidesClass
  • 4.BMetal: Oxygen = 3:4 and similarDivision
  • 4.BBWith only medium-sized cationsGroup
  • 4.BBGarpenbergiteSpecies

Literature, links & citation

Citations
  1. 2021Miyawaki, Ritsuro, Hatert, Frédéric, Pasero, Marco, Mills, Stuart J. (2021) IMA Commission on New Minerals, Nomenclature and Classification (CNMNC) – Newsletter 61. European Journal of Mineralogy, 33 (3) 299-304 doi:10.5194/ejm-33-299-2021 DOI: 10.5194/ejm-33-299-2021
  2. 2022(2022) Garpenbergite. Handbook of Mineralogy. Mineralogical Society of America
  3. 2022Holtstam, Dan, Bindi, Luca, Förster, Hans-Jürgen, Karlsson, Andreas, Gatedal, Kjell (2022) Garpenbergite, Mn6□As5+Sb5+O10(OH)2, a new mineral related to manganostibite, from the Garpenberg Zn–Pb–Ag deposit, Sweden. Mineralogical Magazine, 86 (1) 1-8 doi:10.1180/mgm.2022.6DOI: 10.1180/mgm.2022.6
