Gearksutite

CaAlF4(OH) · H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Gak
Discovered
1868
Also known as
  • Evigtokite
  • Gearksite
  • Gearksutiet
  • +1 more

Where it forms, where it's found

Type locality
Ivigtut Mine
  1. Ivigtut stock
  2. Arsuk Fjord
  3. Sermersooq
  4. Greenland

61.2061°, -48.1756°

71recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Opaque
Colour
white · pale rose · colourless (including in transmitted light)

transparent in thin fibers

Streak
white
Cleavage
Imperfect/Fair

On (110).

Density
2.768 g/cm³

Optical

Optical type
Biaxial (-)
Refractive index
1.448 – 1.456
Surface relief
Low
Principal indices
nα 1.448 · nβ 1.454 · nγ 1.456
Dispersion
r > v distinct
UV response
Compact, massive material fluoresces dark violet to bluish gray; powdery material fluoresces yellowish brown.
Michel-Lévy diagramhighlighted lineδ = 0.0080
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]80 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation80 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
#2
Cell parameters
a = 4.940(1) Å · b = 6.810(1) Å · c = 6.978(1) Å
Cell angles
α = 101.12 ° · β = 94.86 ° · γ = 110.07 °
Ratio a:b:c
1 : 1.379 : 1.413
Unit cell volume
213.43 ų
Z
2
Morphology

Massive; nodular with an earthy to chalky character. Consisting of very minute needles with inclined extinction.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
9FFluorineFluorine418.99875.992
42.67%
20CaCalciumCalcium140.07840.078
22.51%
8OOxygenOxygen215.99931.998
17.97%
13AlAluminiumAluminium126.98226.982
15.15%
1HHydrogenHydrogen31.0083.024
1.70%
Total178.074100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Evigtokite
  • Gearksite
  • Gearksutiet
  • Paragearksutite

In other languages

German
Gearksutit
Italian
Gearksutite

Classification

Strunz
10th ed.

3.CC.05

  • 3HalidesClass
  • 3.CComplex halidesDivision
  • 3.CCSoro-aluminofluoridesGroup
  • 3.CC.05GearksutiteSpecies
Dana
8th ed.

11.06.08.01

  • 11Halide ComplexesClass
  • 11.06Aluminofluorides - Isolated OctahedraType
  • 11.06.08— unnamed intermediate level —Group
  • 11.06.08.01GearksutiteSpecies
CIM

8.6.12

  • 8Halides - Fluorides, Chlorides, Bromides and Iodides; also Fluoborates and FluosilicatesClass
  • 8.6Halides of AlGroup
  • 8.6.12GearksutiteSpecies

Literature, links & citation

Citations
  1. 1862Thomsen, J. (1862) Nogle Meddelelser angaaende Kryolothindustrien. Tidsskrift for Physik og Chemie: 321-332 (328).
  2. 1868Dana, James D., Brush, George Jarvis (1868) A System of Mineralogy (5th ed.). p.882
  3. 1883Flight, W. (1883) Two new aluminous mineral species, evigtokite and liskeardite. Journal of the Chemical Society: 43: 140-142. (as evigtokite)
  4. 1883Groth, P. (1883) Neitrage zur Kenntniss der naturlichen Fluorverbindungen, 1. Die Krolithgruppe. Zeitschrift für Krystallographie und Mineralogie: 7: 457-493 (460,481).
  5. 1885Cross, W.; Hillebrand, W.F. (1885) Contributions to the mineralogy of the Rocky Mountains. Bulletin 20. US Geological Survey 114 pp. doi:10.3133/b20 DOI: 10.3133/b20
