Geminite

Cu2+(AsO3OH) · H2O
IMA status
  • Approved
IMA symbol
Gem
Discovered
1988
IMA approved
1988
Also known as
  • Geminiet
  • IMA1988-045

Where it forms, where it's found

Type locality
Cap Garonne Mine
  1. Le Pradet
  2. Toulon
  3. Var
  4. Provence-Alpes-Côte d'Azur
  5. France

43.0814°, 6.0322°

11recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789103 – 3.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Light green to sea green
Streak
Pale green
Tenacity
brittle
Cleavage
Perfect

(001)

Fracture
Irregular/Uneven
Density
3.70 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 75° · 2V calc = 72°
Refractive index
1.656 – 1.77
Surface relief
High
Principal indices
nα 1.656 · nβ 1.692 · nγ 1.770
Pleochroism
Weak

α = β = colorless γ = pale green to pale gray

Dispersion
weak
UV response
None
Michel-Lévy diagramhighlighted lineδ = 0.1140
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]1140 nm3rd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation1140 nm
Order3rd order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
#2
Cell parameters
a = 6.63 Å · b = 8.11 Å · c = 15.73 Å
Cell angles
α = 92.01 ° · β = 93.87 ° · γ = 95.02 °
Ratio a:b:c
1 : 1.223 : 2.373
Z
16
Morphology

Tabular (001), slightly elongate [100].

Twinning

Twinned polysynthetically parallel to (001).

Type-locality form

Abundant euhedral, intergrown crystals up to 0.3 x 0.06 mm.

Comment

Non-standard space-group setting C_1.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen515.99979.995
36.12%
33AsArsenicArsenic174.92274.922
33.83%
29CuCopperCopper163.54663.546
28.69%
1HHydrogenHydrogen31.0083.024
1.36%
Total221.487100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Geminiet
  • IMA1988-045

In other languages

German
Geminit · IMA 1988-045
Italian
Geminite

Classification

Strunz
10th ed.

8.CB.30

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.CPhosphates without additional anions, with H2ODivision
  • 8.CBWith only medium-sized cations, RO4:H2O = 1:1Group
  • 8.CB.30GeminiteSpecies
Dana
8th ed.

40.05.12.01

  • 40Hydrated Normal Phosphates, Arsenates and VanadatesClass
  • 40.05AXO4·xH2OType
  • 40.05.12— unnamed intermediate level —Group
  • 40.05.12.01GeminiteSpecies
CIM

20.1.7

  • 20Arsenates (also arsenates with phosphate, but without other anions)Class
  • 20.1Arsenates of CuGroup
  • 20.1.7GeminiteSpecies

Literature, links & citation

Citations
  1. 1990Sarp, H., Perroud, P. (1990) La geminite, Cu2As2O7·3H2O, un nouveau minéral de la mine de Cap Garonne, Var, France. Schweizerische Mineralogische und Petrographische Mitteilungen: 70: 309-314.
  2. 1992Jambor, John L. (1992) New Mineral Names. American Mineralogist, 77 (5-6) 670-675
  3. 1995Cooper, M. A., Hawthorne, F. C. (1995) The crystal structure of geminite, Cu2+(AsO3OH)(H2O), a heteropolyhedral sheet structure. The Canadian Mineralogist, 33 (5) 1111-1118
  4. 1996Prencipe, M., Pushcharovsky, D.Y., Sarp, H., Ferraris, G. (1996) Comparative crystal chemistry of geminite Cu[AsO3OH]H2O and related minerals. Moscow University Geology Bulletin: 51: 51-58.
  5. 1996Jambor, J.L., Pertsev, N.N., Roberts, A.C. (1996) New mineral names. American Mineralogist: 81: 766-770.
