Georgechaoite

KNaZrSi3O9 · 2H2O
IMA status
  • Approved
IMA symbol
Gch
Discovered
1985
Also known as
  • Georgechaoiet
  • IMA1984-024

Where it forms, where it's found

Geological setting

miarolitic cavities in Nepheline syenite laccolith

Type locality
Wind Mountain
  1. Cornudas Mountains
  2. Otero County
  3. New Mexico
  4. USA

32.0253°, -105.5159°

6recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Colour
Colorless · white
Cleavage
None Observed
Fracture
Conchoidal
Density
2.70 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 67° · 2V calc = 68°
Refractive index
1.578 – 1.606
Surface relief
Moderate
Principal indices
nα 1.578 · nβ 1.597 · nγ 1.606
Pleochroism
Non-pleochroic
Dispersion
very weak
UV response
none observed
Michel-Lévy diagramhighlighted lineδ = 0.0280
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]280 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation280 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Cell parameters
a = 11.38 Å · b = 12.94 Å · c = 6.73 Å
Ratio a:b:c
1 : 1.137 : 0.591
Twinning

interpenetration twins by a halfturn about [023]

Type-locality form

interpenetrent twins

Comment

p21nb

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1115.999175.989
42.14%
40ZrZirconiumZirconium191.22491.224
21.85%
14SiSiliconSilicon328.08584.255
20.18%
19KPotassiumPotassium139.09839.098
9.36%
11NaSodiumSodium122.99022.990
5.50%
1HHydrogenHydrogen41.0084.032
0.97%
Total417.588100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Fe
  • Ti

Synonyms

  • Georgechaoiet
  • IMA1984-024

In other languages

German
Georgechaoit · IMA 1984-024
Italian
Georgechaoite
Chinese
乔治赵石

Classification

Strunz
10th ed.

9.DM.15

  • 9SilicatesClass
  • 9.DInosilicatesDivision
  • 9.DMInosilicates with 6-periodic single chainsGroup
  • 9.DM.15GeorgechaoiteSpecies
Dana
8th ed.

59.02.02.04

  • 59Cyclosilicates Three-membered RingsClass
  • 59.02Three-Membered Rings, hydratedType
  • 59.02.02Catapleiite groupGroup
  • 59.02.02.04GeorgechaoiteSpecies
CIM

14.10.18

  • 14Silicates not Containing AluminumClass
  • 14.10Silicates of Zr or HfGroup
  • 14.10.18GeorgechaoiteSpecies

Literature, links & citation

Citations
  1. 1985Boggs, R.L., and Ghose, S. (1985) Georgechaoite NaKZrSi3O9•2H2O, a new mineral species from Wind Mountain, New Mexico. The Canadian Mineralogist: 23: 1-4.
  2. 1985Ghose, S. and Thakur, P. (1985) The crystal structure of georgechaoite, NaKZrSi3O9.2H2O. The Canadian Mineralogist: 23: 5-10.
  3. 2001(2001) Georgechaoite. Handbook of Mineralogy. Mineralogical Society of America
