Georgiadesite

Pb4(As3+O3)Cl4(OH)
IMA status
  • Approved
  • Grandfathered
IMA symbol
Ggd
Discovered
1907
Also known as
  • Georgiadesiet

Where it forms, where it's found

Geological setting

N/A (occurred in altered lead slag)

Type locality
Vrysaki Point slag locality
  1. Velatouri
  2. Lavreotiki
  3. East Attica
  4. Attica
  5. Greece

37.7461°, 24.0806°

6recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789103.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
White · brownish yellow · colourless in transmitted light.
Cleavage
None Observed
Density
6.3 g/cm³

Optical

Optical type
Biaxial (+)
Refractive index
2.17 – 2.18
Surface relief
Very high
Principal indices
nα 2.17 · nβ 2.17 · nγ 2.18
Dispersion
extreme
Extinction
Y = b; Z = c.
Notes

2V very large.

Michel-Lévy diagramhighlighted lineδ = 0.0100
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]100 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation100 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P21/c
Cell parameters
a = 13.803(10) Å · b = 7.910(2) Å · c = 10.812(4) Å
Cell angles
β = 102.68(3) °
Ratio a:b:c
1 : 0.573 : 0.783
Z
1
Morphology

Crystals stubby, pseudo-hexagonal tablets with a platy composite structure parallel to [100] (apparently due to lamellar twinning). (001) grooved and striated [010].

Twinning

Apparent lamellar twinning on (100) and (104)

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
82PbLeadLead4207.200828.800
74.63%
17ClChlorineChlorine435.450141.800
12.77%
33AsArsenicArsenic174.92274.922
6.75%
8OOxygenOxygen415.99963.996
5.76%
1HHydrogenHydrogen11.0081.008
0.09%
Total1110.526100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Georgiadesiet

In other languages

French
georgiadésite
German
Georgiadesit
Spanish
Georgiadesita
Italian
georgiadesite
Chinese
氯砷铅石

Classification

Strunz
10th ed.

4.JB.70

  • 4OxidesClass
  • 4.JArsenites, antimonites, bismuthites, sulfites, selenites, tellurites; iodatesDivision
  • 4.JBArsenites, antimonites, bismuthites; with additional anions, without H2OGroup
  • 4.JB.70GeorgiadesiteSpecies
Dana
8th ed.

41.01.03.01

  • 41Anhydrous Phosphates, Etc.containing Hydroxyl or HalogenClass
  • 41.01(AB)m(XO4)pZq, where m:p > 4:1Type
  • 41.01.03— unnamed intermediate level —Group
  • 41.01.03.01GeorgiadesiteSpecies
CIM

22.2.13

  • 22Phosphates, Arsenates or Vanadates with other AnionsClass
  • 22.2Phosphates, arsenates or vanadates with chlorideGroup
  • 22.2.13GeorgiadesiteSpecies

Literature, links & citation

Citations
  1. 1907Lacroix, A. and Schulten, A. de. (1907): Sur une nouvellle espèce minérale, provenant des scories plombeuses athéniennes du Laurium. Comptes rendus hebdomadaires des séances de l'Académie des sciences, 45, 783-784. (in French).
  2. 1908Lacroix, Alfred, De Schulten, August Benjamin (1908) Note sur les minéraux plombifères des scories athéniennes du Laurion. Bulletin de Minéralogie, 31 (2). 79-90 doi:10.3406/bulmi.1908.3288 DOI: 10.3406/bulmi.1908.3288
  3. 1951Palache, Charles; Berman, Harry; Frondel, Clifford (1951) The System of Mineralogy (7th ed.) Vol. 2 - Halides, Nitrates, Borates, Carbonates, Sulfates, Phosphates, Arsenates, Tungstates, Molybdates, Etc. John Wiley and Sons.
  4. 1983Roland C. Rouse, , Pete J. Dunn, (1983) New data on georgiadesite. Mineralogical Magazine, 47 (343) 219-220 doi:10.1180/minmag.1983.047.343.12 DOI: 10.1180/minmag.1983.047.343.12
  5. 1984Dunn, Pete J., Fleischer, Michael, Francis, Carl A., Langley, Richard H., Kissin, Stephen A., Shigley, Hames E., Vanko, David A., Zilczer, Janet A. (1984) New mineral names. American Mineralogist, 69 (7-8) 810-815
