Gerdtremmelite

ZnAl2(AsO4)(OH)5
IMA status
  • Approved
IMA symbol
Gtm
Discovered
1985
Also known as
  • Gerdtremmeliet
  • IMA1983-049a

Where it forms, where it's found

Type locality
Tsumeb Mine (Ongopolo Mine)
  1. Tsumeb
  2. Oshikoto Region
  3. Namibia

-19.2270°, 17.7276°

1recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Transparency
Transparent
Colour
Yellowish brown to dark brown
Streak
White
Cleavage
None Observed
Fracture
None observed
Density
3.66 g/cm³

Optical

Optical type
Biaxial
Refractive index
1.73 – 1.84
Surface relief
High
Principal indices
nα 1.73 – 1.74 · nγ 1.83 – 1.84
Dispersion
r > v
UV response
None observed
Michel-Lévy diagramhighlighted lineδ = 0.1000
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]1000 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation1000 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Triclinic
Cell parameters
a = 5.169(5) Å · b = 13.038(9) Å · c = 4.931(4) Å
Cell angles
α = 98.78 ° · β = 100.80(6) ° · γ = 78.73 °
Ratio a:b:c
1 : 2.522 : 0.954
Z
2
Comment

Point Group: _1 or 1.; Space Group: P_1 or P1.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen915.999143.991
41.94%
33AsArsenicArsenic174.92274.922
21.82%
30ZnZincZinc165.38065.380
19.05%
13AlAluminiumAluminium226.98253.964
15.72%
1HHydrogenHydrogen51.0085.040
1.47%
Total343.297100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Gerdtremmeliet
  • IMA1983-049a

In other languages

French
gerdtremmélite
German
Gerdtremmelit · IMA 1983-049a
Italian
Gerdtremmelite

Classification

Strunz
10th ed.

8.BE.40

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.BPhosphates, etc., with additional anions, without H2ODivision
  • 8.BEWith only medium-sized cations, (OH, etc.):RO4 > 2:1Group
  • 8.BE.40GerdtremmeliteSpecies
Dana
8th ed.

41.03.07.01

  • 41Anhydrous Phosphates, Etc.containing Hydroxyl or HalogenClass
  • 41.03(AB)3(XO4)ZqType
  • 41.03.07— unnamed intermediate level —Group
  • 41.03.07.01GerdtremmeliteSpecies
CIM

20.4.10

  • 20Arsenates (also arsenates with phosphate, but without other anions)Class
  • 20.4Arsenates of Group III metals (Al, rare earths)Group
  • 20.4.10GerdtremmeliteSpecies

Literature, links & citation

Citations
  1. 1985Schmetzer, K., Medenbach, O. (1985) Gerdtremmelite, (Zn,Fe)(Al,Fe)2[(AsO4)|(OH)5], a new mineral from Tsumeb, Namibia. Neues Jahrbuch für Mineralogie - Monatshefte, 1985. 1-6
  2. 1986Hawthorne, F.C., Dunn, P.J., Grice, J.D., Puziewicz, J., Shigley, J.E. (1986) New mineral names. American Mineralogist: 71: 845-847.
  3. 2005(2005) Gerdtremmelite. Handbook of Mineralogy. Mineralogical Society of America
