Gilalite

Cu5Si6O17 · 7H2O
IMA status
  • Approved
IMA symbol
Gil
Discovered
1980
Also known as
  • Gilaliet
  • IMA1979-021

Where it forms, where it's found

Geological setting

Retrograde or mesogene mineral occurring in tactites.

Type locality
Christmas Mine
  1. Christmas
  2. Banner Mining District
  3. Gila County
  4. Arizona
  5. USA

33.0583°, -110.7458°

6recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Translucent green · blue-green
Tenacity
waxy
Density
2.72 g/cm³

Optical

Optical type
Biaxial (-)
Refractive index
1.56 – 1.635
Surface relief
Moderate
Principal indices
nα 1.56 · nβ 1.635 · nγ 1.635
Pleochroism
Weak

Weak in drab grayish green.

Dispersion
none
Extinction
Blades extinguish up to 8° from Z || length.
Notes

2Vmeasured = Very small. Absorption: Z > X = Y.

Michel-Lévy diagramhighlighted lineδ = 0.0750
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]750 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation750 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Monoclinic
Cell parameters
a = 13.38 Å · b = 19.16 Å · c = 9.02 Å
Cell angles
β = 90 °
Ratio a:b:c
1 : 1.432 : 0.674
Z
4
Type-locality form

Spherules of radial fibers up to 0.2 mm or more in length.

Comment

Neither point group nor space group known.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2415.999383.976
43.42%
29CuCopperCopper563.546317.730
35.93%
14SiSiliconSilicon628.085168.510
19.05%
1HHydrogenHydrogen141.00814.112
1.60%
Total884.328100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Mn
  • Mg
  • Ca

Synonyms

  • Gilaliet
  • IMA1979-021

In other languages

French
gilalite
German
Gilalith · IMA 1979-021
Spanish
gilalito
Italian
gilalite

Classification

Strunz
10th ed.

9.HE.05

  • 9SilicatesClass
  • 9.HUnclassified silicatesDivision
  • 9.HEWith Cu, ZnGroup
  • 9.HE.05GilaliteSpecies
Dana
8th ed.

78.04.04.01

  • 78Unclassified SilicatesClass
  • 78.04Unclassified silicates possible inosilicatesType
  • 78.04.04— unnamed intermediate level —Group
  • 78.04.04.01GilaliteSpecies
CIM

14.2.4

  • 14Silicates not Containing AluminumClass
  • 14.2Silicates of CuGroup
  • 14.2.4GilaliteSpecies

Literature, links & citation

Citations
  1. 1980Fleischer, M., Cabri, L. J., Chao, G. Y., Pabst, A. (1980) New mineral names. American Mineralogist, 65 (9-10). 1065-1070
  2. 1980Cesbron, F. P., Williams, S. A. (1980) Apachite and gilalite, two new copper silicates from Christmas, Arizona. Mineralogical Magazine, 43 (329) 639-641 doi:10.1180/minmag.1980.043.329.12 DOI: 10.1180/minmag.1980.043.329.12
  3. 2001(2001) Gilalite. Handbook of Mineralogy. Mineralogical Society of America
