Ginorite

Ca2B14O20(OH)6 · 5H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Gnr
Discovered
1934
Also known as
  • Cryptomorphit
  • Cryptomorphita
  • Cryptomorphite (of Chase)
  • +1 more

Where it forms, where it's found

Geological setting

Veins in sandstone.

Type locality
Sasso Pisano
  1. Castelnuovo di Val di Cecina
  2. Pisa Province
  3. Tuscany
  4. Italy

43.1674°, 10.8648°

9recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
White
Streak
White
Cleavage
Distinct/Good

On (010) with unstated quality.

Density
2.07 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 42° · 2V calc = 42°
Refractive index
1.517 – 1.577
Surface relief
Moderate
Principal indices
nα 1.517 · nβ 1.524 · nγ 1.577
Dispersion
none
Extinction
Y = b; Z ∧ c = 39°
Notes

Positive elongation

Michel-Lévy diagramhighlighted lineδ = 0.0600
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]600 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation600 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P21/c
Cell parameters
a = 12.738(1) Å · b = 14.240(1) Å · c = 12.750(1) Å
Cell angles
β = 101.163(2) °
Ratio a:b:c
1 : 1.118 : 1.001
Z
4
Morphology

Crystals are flat tablets (010). Dense masses. Lozenge or rhomb shaped plates with acute angle of ~78-79°.

Type-locality form

Lozenge-shaped plates. Minutely granular.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen3115.999495.969
66.70%
5BBoronBoron1410.810151.340
20.35%
20CaCalciumCalcium240.07880.156
10.78%
1HHydrogenHydrogen161.00816.128
2.17%
Total743.593100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Cryptomorphit
  • Cryptomorphita
  • Cryptomorphite (of Chase)
  • Ginoriet

In other languages

French
Ginorite
German
Ginorit
Italian
Ginorite
Chinese
水硼钙石

Classification

Strunz
10th ed.

6.FC.15

  • 6BoratesClass
  • 6.FHexaboratesDivision
  • 6.FCPhyllo-hexaboratesGroup
  • 6.FC.15GinoriteSpecies
Dana
8th ed.

26.06.07.01

  • 26Hydrated Borates Containing Hydroxyl or HalogenClass
  • 26.06HexaboratesType
  • 26.06.07— unnamed intermediate level —Group
  • 26.06.07.01GinoriteSpecies
CIM

9.3.19

  • 9BoratesClass
  • 9.3Borates of Ca and SrGroup
  • 9.3.19GinoriteSpecies

Literature, links & citation

Citations
  1. 1861How, Henry (1861) On natro-boro-calcite and another borate occurring in the gypsum of Nova Scotia. The American Journal of Science and Arts, S. 2 Vol. 32. 9-13
  2. 1934D'Achiardi (1934) Ginorite, nuovo borato di calcio di Sasso Pisano. Periodico di Mineralogia: 5: 22-32.
  3. 1935Foshag, W. F. (1935) New mineral names. American Mineralogist, 20 (5). 403-404
  4. 1938Kracek, F.C., Morey, G.W., Merwin, H.E. (1938) The system water–boron oxide. American Journal of Science: 235-A: 143-171.
  5. 1951Palache, Charles; Berman, Harry; Frondel, Clifford (1951) The System of Mineralogy (7th ed.) Vol. 2 - Halides, Nitrates, Borates, Carbonates, Sulfates, Phosphates, Arsenates, Tungstates, Molybdates, Etc. John Wiley and Sons.
