Gismondine-Sr

Sr4(Si8Al8O32) · 9H2O
IMA status
  • Approved
IMA symbol
Gis-Sr
Also known as
  • Gismondien-Sr
  • IMA2021-043

Where it forms, where it's found

Geological setting

Gehlenite hornfels.

Type locality
Paralava outcrops
  1. Wadi Halamish
  2. Hatrurim Basin
  3. Tamar Regional Council
  4. Beersheba Subdistrict
  5. Southern District
  6. Israel

31.1617°, 35.2914°

2recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
White
Streak
White
Tenacity
brittle
Cleavage
Imperfect/Fair

Imperfect on [101].

Fracture
Irregular/Uneven
Density
2.301 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 70 – 80° · 2V calc = 81.8°
Refractive index
1.488 – 1.495
Surface relief
Low
Principal indices
nα 1.488 · nβ 1.492 · nγ 1.495
UV response
None
Michel-Lévy diagramhighlighted lineδ = 0.0070
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]70 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation70 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
#39
Cell parameters
a = 14.0256(2) Å · b = 10.4590(1) Å · c = 13.7936(1) Å
Ratio a:b:c
1 : 0.746 : 0.983
Type-locality form

Spherical aggregates to 180 μm or pseudotetragonal bipyramids to 50 μm.

Comment

the space group is B2212 for comparison to gismondine-Ca

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen4115.999655.959
44.77%
38SrStrontiumStrontium487.620350.480
23.92%
14SiSiliconSilicon828.085224.680
15.34%
13AlAluminiumAluminium826.982215.856
14.73%
1HHydrogenHydrogen181.00818.144
1.24%
Total1465.119100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Gismondien-Sr
  • IMA2021-043

In other languages

German
Gismondin-Sr · IMA 2021-043
Italian
gismondina-Sr · IMA2021-043

Classification

Strunz
10th ed.

9.GC

  • 9SilicatesClass
  • 9.GTektosilicates with zeolitic H2O; zeolite familyDivision
  • 9.GCChains of doubly-connected 4-membered ringsGroup
  • 9.GCGismondine-SrSpecies

Group, growth & confusion

In the same group
1 members

Literature, links & citation

Citations
  1. 2021Miyawaki, Ritsuro, Hatert, Frédéric, Pasero, Marco, Mills, Stuart J. (2021) IMA Commission on New Minerals, Nomenclature and Classification (CNMNC) CNMNC Newsletter No 63. Mineralogical Magazine, 85 (6) 910-915 doi:10.1180/mgm.2021.74 DOI: 10.1180/mgm.2021.74
  2. 2022(2022) Gismondine-Sr. Handbook of Mineralogy. Mineralogical Society of America
  3. 2023Skrzyńska, Katarzyna, Cametti, Georgia, Galuskina, Irina O., Vapnik, Yevgeny, Galuskin, Evgeny V. (2023) Gismondine-Sr, Sr4(Al8Si8O32)·9H2O, a new strontium dominant, orthorhombic zeolite of the gismondine series from the Hatrurim Complex, Israel. American Mineralogist, 108 (2) 249-258 doi:10.2138/am-2022-8376DOI: 10.2138/am-2022-8376
  4. 2023Skrzyńska, Katarzyna, Cametti, Georgia, Juroszek, Rafał, Schӓfer, Christof, Galuskina, Irina (2023) New data on minerals with the GIS framework-type structure: gismondine-Sr from the Bellerberg volcano, Germany, and amicite and Ba-rich gismondine from the Hatrurim Complex, Israel. Mineralogical Magazine, 87 (3) 443-454 doi:10.1180/mgm.2023.27DOI: 10.1180/mgm.2023.27
