Gladite

CuPbBi5S9
IMA status
  • Approved
  • Grandfathered
IMA symbol
Gld
Discovered
1924
Also known as
  • Gladiet

Where it forms, where it's found

Geological setting

Hydrothermal

Type locality
Gladhammar mines
  1. Västervik
  2. Kalmar County
  3. Sweden

57.7194°, 16.4250°

67recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789102 – 3/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
Tin-white to lead-grey
Streak
Black
Cleavage
Distinct/Good

(010) good (100) fair

Density
6.96 g/cm³

Optical

Optical colour
Tin-white to lead-grey
Tropism
Anisotropic
Reflectance R%
(44.0, 46.0) 400, (44.9, 46.2) 440, (45.1, 46.4) 480, (45.0, 46.8) 520, (44.8, 46.9) 560, (44.6, 46.7) 600, (44.1, 46.0) 640, (43.5, 44.9) 680, (43.2, 44.4) 700
Reflected-light panel
44.4 %anisotropic · dual curve
Specimen sRGB 235, 166, 92
White reference100 % reflector under same lamp
R₁ R₂
Mode
Reflected colour
Tin-white to lead-grey

Crystallography

Crystal system
Orthorhombic
Cell parameters
a = 4.0044(4) Å · b = 33.575(3) Å · c = 11.480(1) Å
Ratio a:b:c
1 : 8.385 : 2.867
Z
4
Morphology

Prismatic [001] to 2cm, lacking terminal faces.

Type-locality form

Crystals, 2 cm long and 2-6 mm thick.

Comment

SG Pmcn

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
83BiBismuthBismuth5208.9801044.900
65.13%
16SSulfurSulfur932.060288.540
17.99%
82PbLeadLead1207.200207.200
12.92%
29CuCopperCopper163.54663.546
3.96%
Total1604.186100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Fe

Synonyms

  • Gladiet

In other languages

German
Gladit
Italian
Gladite

Classification

Strunz
10th ed.

2.HB.05a

  • 2Sulfides and SulfosaltsClass
  • 2.HSulfosalts of SnS archetypeDivision
  • 2.HBWith Cu, Ag, Fe, Sn and PbGroup
  • 2.HB.05aGladiteSpecies
Dana
8th ed.

03.04.05.03

  • 03SulfosaltsClass
  • 03.04ø = 3Type
  • 03.04.05Aikinite Group (Orthorhombic containing Pb, Cu, Bi, & S)Group
  • 03.04.05.03GladiteSpecies
CIM

5.7.4

  • 5Sulphosalts - Sulpharsenites and Sulphobismuthites (those containing Sn, Ge,or V are in Section 6)Class
  • 5.7Sulpharsenites etc. of Pb and other metalsGroup
  • 5.7.4GladiteSpecies

Literature, links & citation

Citations
  1. 1924Johansson, K. (1924) Bidrag till Gladhammar-gruvornas mineralogi [Contribution to the mineralogy of the Gladhammar mines]. Arkiv für Kemi, Mineralogi och Geologi [Archive for Chemistry, Mineralogy and Geology], 9 (8) 1-22
  2. 1925Foshag, W.F. (1925) New minerals: new species. American Mineralogist: 10: 157-158.
  3. 1944Palache, Charles, Berman, Harry, Frondel, Clifford (1944) The System of Mineralogy (7th ed.) Vol. 1 - Elements, Sulfides, Sulfosalts, Oxides. John Wiley and Sons, New York.
  4. 1974Syneček, V., Hybler, J. (1974) The crystal structure of krupkaite, CuPbBi3S6, and of gladite, CuPbBi5S9, and the classification of superstructures in the bismuthinite-aikinite group. Neues Jahrbuch für Mineralogie - Monatshefte, 1974. 541-560
  5. 1976Mumme, William G., Welin, Eric, Weunsch, B. J. (1976) Crystal chemistry and proposed nomenclature for sulfosalts intermediate in the system bismuthinite-aikinite (Bi2S3-CuPbBiS3). American Mineralogist, 61 (1-2). 15-20
