Where it forms, where it's found
- Geological setting
Hydrothermal
- Type locality
- Gladhammar mines
- Västervik
- Kalmar County
- Sweden
57.7194°, 16.4250°
67recorded occurrences
Safety & handling
Physical
Optical
- Optical colour
- Tin-white to lead-grey
- Tropism
- Anisotropic
- Reflectance R%
- (44.0, 46.0) 400, (44.9, 46.2) 440, (45.1, 46.4) 480, (45.0, 46.8) 520, (44.8, 46.9) 560, (44.6, 46.7) 600, (44.1, 46.0) 640, (43.5, 44.9) 680, (43.2, 44.4) 700
Reflected-light panel
R̄ 44.4 %anisotropic · dual curve
Specimen
White reference
R₁ R₂
Mode
Crystallography
- Cell parameters
- a = 4.0044(4) Å · b = 33.575(3) Å · c = 11.480(1) Å
- Ratio a:b:c
- 1 : 8.385 : 2.867
- Z
- 4
- Morphology
Prismatic [001] to 2cm, lacking terminal faces.
- Type-locality form
Crystals, 2 cm long and 2-6 mm thick.
- Comment
SG Pmcn
Crystal structure
Chemical composition
Synonyms
- Gladiet
In other languages
- German
- Gladit
- Italian
- Gladite
Classification
Strunz
10th ed.2.HB.05a
- 2Sulfides and SulfosaltsClass
- 2.HSulfosalts of SnS archetypeDivision
- 2.HBWith Cu, Ag, Fe, Sn and PbGroup
- 2.HB.05aGladiteSpecies
Dana
8th ed.03.04.05.03
- 03SulfosaltsClass
- 03.04ø = 3Type
- 03.04.05Aikinite Group (Orthorhombic containing Pb, Cu, Bi, & S)Group
- 03.04.05.03GladiteSpecies
CIM
—5.7.4
- 5Sulphosalts - Sulpharsenites and Sulphobismuthites (those containing Sn, Ge,or V are in Section 6)Class
- 5.7Sulpharsenites etc. of Pb and other metalsGroup
- 5.7.4GladiteSpecies
Literature, links & citation
Citations
- 1924Johansson, K. (1924) Bidrag till Gladhammar-gruvornas mineralogi [Contribution to the mineralogy of the Gladhammar mines]. Arkiv für Kemi, Mineralogi och Geologi [Archive for Chemistry, Mineralogy and Geology], 9 (8) 1-22
- 1925Foshag, W.F. (1925) New minerals: new species. American Mineralogist: 10: 157-158.
- 1944Palache, Charles, Berman, Harry, Frondel, Clifford (1944) The System of Mineralogy (7th ed.) Vol. 1 - Elements, Sulfides, Sulfosalts, Oxides. John Wiley and Sons, New York.
- 1974Syneček, V., Hybler, J. (1974) The crystal structure of krupkaite, CuPbBi3S6, and of gladite, CuPbBi5S9, and the classification of superstructures in the bismuthinite-aikinite group. Neues Jahrbuch für Mineralogie - Monatshefte, 1974. 541-560
- 1976Mumme, William G., Welin, Eric, Weunsch, B. J. (1976) Crystal chemistry and proposed nomenclature for sulfosalts intermediate in the system bismuthinite-aikinite (Bi2S3-CuPbBiS3). American Mineralogist, 61 (1-2). 15-20
