Griphite

Ca(Mn2+,Na,Li)6Fe2+Al2(PO4)6(F,OH)2
IMA status
  • Approved
  • Grandfathered
IMA symbol
Gph
Discovered
1891
Also known as
  • Griphiet
  • Griphita

Where it forms, where it's found

Geological setting

Granite pegmatite.

Type locality
Everly Mine (Riverton lode)
  1. Harney City
  2. Pennington County
  3. South Dakota
  4. USA
9recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Resinous · Vitreous
Transparency
Translucent
Colour
Yellow · dark-brown · brownish-black · yellowish brown to brown in transmitted light.
Tenacity
brittle
Cleavage
None Observed
Fracture
Irregular/Uneven · Conchoidal
Density
3.4 g/cm³

Optical

Optical type
Isotropic
Isotropy testPPL ↔ XPL diagnostic
PPL intrinsic colour; no change on stage rotation
XPL extinct at every orientation

Crystallography

Crystal system
Isometric
Space group
Pa3
Cell parameters
a = 12.22 Å
Morphology

Massive; reniform at times.

Type-locality form

Kidney shaped masses weighing up to 22 kg (50 lbs).

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2615.999415.974
31.98%
25MnManganeseManganese654.938329.628
25.34%
15PPhosphorusPhosphorus630.974185.844
14.29%
11NaSodiumSodium622.990137.940
10.60%
26FeIronIron155.84555.845
4.29%
13AlAluminiumAluminium226.98253.964
4.15%
3LiLithiumLithium66.94041.640
3.20%
20CaCalciumCalcium140.07840.078
3.08%
9FFluorineFluorine218.99837.996
2.92%
1HHydrogenHydrogen21.0082.016
0.15%
Total1300.925100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Griphiet
  • Griphita

In other languages

German
Griphit
Italian
Griphite

Classification

Strunz
10th ed.

8.BF.15

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.BPhosphates, etc., with additional anions, without H2ODivision
  • 8.BFWith medium-sized and large cations, (OH, etc.):RO4< 0.5:1Group
  • 8.BF.15GriphiteSpecies
Dana
8th ed.

41.09.03.01

  • 41Anhydrous Phosphates, Etc.containing Hydroxyl or HalogenClass
  • 41.09(AB)5(XO4)3ZqType
  • 41.09.03— unnamed intermediate level —Group
  • 41.09.03.01GriphiteSpecies
CIM

19.12.51

  • 19PhosphatesClass
  • 19.12Phosphates of MnGroup
  • 19.12.51GriphiteSpecies

Literature, links & citation

Citations
  1. 1890Williams, GH (1890) The Greenstone Schist areas of the Menominee and Marquette Regions of Michigan. Vol 62. USGS Bulletin, United States Geological Survey. 1-241
  2. 1891Headden, W.P. (1891) A new phosphate from the Black Hills of South Dakota. American Journal of Science: 141: 415-417.
  3. 1921Larsen, Esper S. (1921) The microscopic determination of the nonopaque minerals. Bulletin 679. US Geological Survey doi:10.3133/b679 DOI: 10.3133/b679
  4. 1942McConnell, Duncan (1942) Griphite, a hydrophosphate garnetoid. American Mineralogist, 27 (6) 452-461
  5. 1946Jaffe, H.W. (1946) A new occurrence of griphite. American Mineralogist: 31: 404-405. (Dwiggins & Yelmgren analysis)
