Häggite

V3+V4+O2(OH)3
IMA status
  • Approved
  • Grandfathered
IMA symbol
Hgg
Also known as
  • Haeggite
  • Häggiet

Where it forms, where it's found

Geological setting

oxidized zone of Colorado Plateau-type U-V deposits.

Type locality
Drill Hole TR-713
  1. Carlile
  2. Crook County
  3. Wyoming
  4. USA

44.4647°, -104.7708°

16recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
Black
Density
3.51 g/cm³

Optical

Optical type
Biaxial
Optical colour
Gray to dark gray
Anisotropism
Very strong yellowish gray to bluish gray.
Tropism
Anisotropic
Reflectance R%
(11.7-11.0) 440, (11.8-11.0) 460, (12.0-11.0) 480, (12.3-11.0) 500, (12.3-11.0) 520, (13.0-11.1) 540, (13.4-11.2) 560, (13.7-11.2) 580, (14.0-11.2) 600, (14.3-11.2) 620, (14.6-11.2) 640, (14.9-11.3) 660, (15.2-11.5) 680, (15.6-11.9) 700

Crystallography

Crystal system
Monoclinic
Space group
C2/m
Cell parameters
a = 12.17(5) Å · b = 2.99(1) Å · c = 4.83(2) Å
Cell angles
β = 94.25(8) °
Ratio a:b:c
1 : 0.246 : 0.397
Z
2
Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
23VVanadiumVanadium250.942101.884
55.10%
8OOxygenOxygen515.99979.995
43.26%
1HHydrogenHydrogen31.0083.024
1.64%
Total184.903100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Haeggite
  • Häggiet

In other languages

German
Häggit
Italian
Häggite

Classification

Strunz
10th ed.

4.HE.25

  • 4OxidesClass
  • 4.HV[5,6] VanadatesDivision
  • 4.HEPhyllovanadatesGroup
  • 4.HE.25HäggiteSpecies
Dana
8th ed.

06.04.03.01

  • 06Hydroxides and Oxides Containing HydroxylClass
  • 06.04MiscellaneousType
  • 06.04.03— unnamed intermediate level —Group
  • 06.04.03.01HäggiteSpecies
CIM

7.12.4

  • 7Oxides and HydroxidesClass
  • 7.12Oxides of V, Nb and TaGroup
  • 7.12.4HäggiteSpecies

Literature, links & citation

Citations
  1. 1958Evans, H. T., Mrose, M. E. (1958) The crystal structures of three new vanadium oxide minerals. Acta Crystallographica, 11 (1) 56-58 doi:10.1107/s0365110x58000141DOI: 10.1107/s0365110x58000141
  2. 1958Fleischer, M. (1958) New Mineral Names. American Mineralogist, 43 (3-4). 378-387
  3. 1960Evans, H. T., Mrose, M. E. (1960) A crystal chemical study of the vanadium oxide minerals, haeggite and doloresite. American Mineralogist, 45 (11-12) 1144-1166
  4. 1978Ryabeva, E.G., Dubakina, L.S., Gorshkov, A.A., Nekrasova, Z.Z., Taichkova, L.I., Khruleva, T.A. (1978) Häggite - new data. Doklady Akademii Nauk SSSR: 243: 1295-1297.
  5. 1980Fleischer, M.; Mandarino, J.A.; Pabst, A. (1980) New mineral names. American Mineralogist, 65 (1-2). 205-210
