Hanksite

KNa22(SO4)9(CO3)2Cl
IMA status
  • Approved
  • Grandfathered
IMA symbol
Hks
Discovered
1883

Where it forms, where it's found

Geological setting

Lacustrine evaporite deposit.

Lacustrine evaporite deposits.

Type locality
Searles Lake
  1. San Bernardino County
  2. California
  3. USA

35.7383°, -117.3739°

12recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103 – 3.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Transparency
Transparent · Translucent
Colour
Colourless to grey · yellow or almost black · colourless in transmitted light
Streak
White
Tenacity
brittle
Cleavage
Distinct/Good

Good on (0001)

Fracture
Irregular/Uneven
Density
2.562 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
1.461 – 1.481
Surface relief
Low
Principal indices
nω 1.481 · nε 1.461
UV response
Pale yellow under LW UV.
Michel-Lévy diagramhighlighted lineδ = 0.0200
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]200 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation200 nm
Order1st order
XPL colour

Crystallography

Crystal system
Hexagonal
Space group
#108
Cell parameters
a = 10.4896(3) Å · c = 21.2415(6) Å
Unit cell volume
2024.11 ų
Z
2
Morphology

Large, short prismatic [0001] to tabular (0001) crystals to 20 cm; also as quartzoids with large (1012); (1010) striated horizontally; crystals frequently in interpenetrating groups.

Type-locality form

Barrel shaped crystals. Roughly spherical aggregates composed of randomly oriented, interpenetrating tabular crystals.

Comment

Cell parameters from Callegari et al (2018)

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen4215.999671.958
42.94%
11NaSodiumSodium2222.990505.780
32.32%
16SSulfurSulfur932.060288.540
18.44%
19KPotassiumPotassium139.09839.098
2.50%
17ClChlorineChlorine135.45035.450
2.27%
6CCarbonCarbon212.01124.022
1.53%
Total1564.848100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

In other languages

French
hanksite
German
Hanksit
Spanish
Hanksita
Italian
Hanksite
Japanese
ハンクス石
Chinese
碳酸芒硝 · 碳钾钠矾

Classification

Strunz
10th ed.

7.BD.30

  • 7SulfatesClass
  • 7.BSulfates (selenates, etc.) with additional anions, without H2ODivision
  • 7.BDWith only large cationsGroup
  • 7.BD.30HanksiteSpecies
Dana
8th ed.

32.03.01.01

  • 32Compound SulfatesClass
  • 32.03Anhydrous Compound Sulfates containing Hydroxyl or HalogenType
  • 32.03.01— unnamed intermediate level —Group
  • 32.03.01.01HanksiteSpecies
CIM

12.2.2

  • 12Carbonates with other anionsClass
  • 12.2Carbonates with sulphateGroup
  • 12.2.2HanksiteSpecies

Group, growth & confusion

Often grow together
1 mineral

Literature, links & citation

Citations
  1. Comptes rendu de l’Académie des sciences de Paris: 123: 1325.
  2. 1885Dana, E.S., Penfield, S.L. (1885) Mineralogical Notes: A large crystal of hanksite. American Journal of Science: 30: 136.
  3. 1885Hidden, W.E. (1885) On hanksite, a new anhydrous sulphato-carbonate of sodium, from San Bernardino County, California. American Journal Of Science, S. 3 Vol. 30. 133-135
  4. 1889Hanks, H.G. (1889) On the occurrence of hanksite in California. American Journal of Science: 137: 63-66.
  5. 1896Pratt, J.H. (1896) On northupite; pirssonite, a new mineral; Gaylussite and hanksite from Borax Lake, San Bernardino County, California. American Journal of Science, 4th. series: 2: 123-135; …Zeitschr. Kristallographie, Band 27: 416-429 (1896); …(abstract): Neues Jahrb., Band 2: 451-455 (1897).
