Haradaite

SrV4+Si2O7
IMA status
  • Approved
IMA symbol
Hra
Discovered
1974
Also known as
  • Haradaiet
  • IMA1963-011

Where it forms, where it's found

Geological setting

Veinlets cutting the massive metamorphosed manganese ores and wallrocks.

Type locality
Yamato mine
  1. Yamato village
  2. Oshima District
  3. Kagoshima Prefecture
  4. Japan
2recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Bright grass green
Streak
Very pale green
Cleavage
Perfect

perfect on (010) distinct (100) and (001)

Density
3.80 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 90° · 2V calc = 78°
Refractive index
1.713 – 1.734
Surface relief
High
Principal indices
nα 1.713 · nβ 1.721 · nγ 1.734
Pleochroism
Strong

a=X= colourless to very pale green, b=Y= colourless to light yellowish green, and c=Z= bluish green.

Dispersion
weak
Michel-Lévy diagramhighlighted lineδ = 0.0210
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]210 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation210 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Cell parameters
a = 7.001 Å · b = 14.64 Å · c = 5.312 Å
Ratio a:b:c
1 : 2.091 : 0.759
Z
4
Type-locality form

Small tablets to 5 mm.

Comment

Space Group: Amam

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen715.999111.993
36.51%
38SrStrontiumStrontium187.62087.620
28.57%
14SiSiliconSilicon228.08556.170
18.31%
23VVanadiumVanadium150.94250.942
16.61%
Total306.725100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Ti
  • Al
  • Fe
  • Mn
  • Cu
  • Pb
  • Ca
  • Ba
  • Na
  • K

Synonyms

  • Haradaiet
  • IMA1963-011

In other languages

German
Haradait · IMA 1963-011
Italian
Haradaite
Japanese
原田石

Classification

Strunz
10th ed.

9.DH.15

  • 9SilicatesClass
  • 9.DInosilicatesDivision
  • 9.DHInosilicates with 4-periodic single chains, Si4O12Group
  • 9.DH.15HaradaiteSpecies
Dana
8th ed.

65.03.01.01

  • 65Inosilicates Single-width, Unbranched Chains, (w=1)Class
  • 65.03Single-Width Unbranched Chains, W=1 with chains P=4Type
  • 65.03.01Haradaite groupGroup
  • 65.03.01.01HaradaiteSpecies
CIM

14.14.4

  • 14Silicates not Containing AluminumClass
  • 14.14Silicates of V and BiGroup
  • 14.14.4HaradaiteSpecies

Literature, links & citation

Citations
  1. Chemical Abstracts: 96: 146305.
  2. 1965ITO, JUN (1965) Synthesis of vanadium silicates: haradaite, goldmanite and roscoelite. Mineralogical Journal, 4 (4). 299-316 doi:10.2465/minerj1953.4.299 DOI: 10.2465/minerj1953.4.299
  3. 1967Takéuchi, Yoshio, Joswig, Werner (1967) The structure of haradaite and a note on the Si-O bond lengths in silicates. Mineralogical Journal, 5 (2) 98-123 doi:10.2465/minerj1953.5.98 DOI: 10.2465/minerj1953.5.98
  4. 1971Fleischer, Michael (1971) New Mineral Names. American Mineralogist, 56 (5-6) 1121-1123
  5. 1974Watanabe, T., Kato, A., Ito, J., Yoshimora, T., Momoi, H., Fukuda, K. (1974) Haradaite, Sr2V2(O2)(Si4O12), a new mineral from the Noda Tamagawa mine, Iwate Prefecture, and the Yamato mine, Kagoshima Prefecture, Japan. 9th General Meeting of the International Mineralogical Association, Berlin Germany: 9: 97-97.
