Hauckite

Fe3+3Mg24Zn18(SO4)4(CO3)2(OH)81
IMA status
  • Approved
IMA symbol
Hck
Discovered
1980
Also known as
  • Hauckiet
  • IMA1979-012

Where it forms, where it's found

Geological setting

Secondary, Mn-rich veins in a Precambrian, metamorphosed Zn-Fe-Mn orebody. Three different parageneses; in all cases the last mineral to form.

Type locality
Sterling Mine
  1. Sterling Hill
  2. Ogdensburg
  3. Sussex County
  4. New Jersey
  5. USA

41.0836°, -74.6047°

2recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102 – 3/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Bright orange · light yellow
Streak
Yellow to light yellow
Tenacity
brittle
Cleavage
Perfect

On (0001)

Density
3.02 g/cm³

Optical

Optical type
Uniaxial (+)
Refractive index
1.63 – 1.638
Surface relief
Moderate
Principal indices
nω 1.63 · nε 1.638
Pleochroism
Visible

O = Golden brown E = Light yellow

UV response
Not fluorescent.
Notes

Absorption: O > E.

Michel-Lévy diagramhighlighted lineδ = 0.0080
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]80 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation80 nm
Order1st order
XPL colour

Crystallography

Crystal system
Hexagonal
Space group
#124
Cell parameters
a = 9.17 Å · c = 30.21 Å
Z
1
Morphology

Hexagonal tablets, extremely flattened on (0001), with (0110) and (0001). Aggregated into almost spherical to imperfect rosettes.

Type-locality form

Hexagonal crystals, extremely flattened on (0001) occurring in highly irregular clusters that resemble rosettes.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen10315.9991647.897
43.26%
30ZnZincZinc1865.3801176.840
30.89%
12MgMagnesiumMagnesium2424.305583.320
15.31%
26FeIronIron355.845167.535
4.40%
16SSulfurSulfur432.060128.240
3.37%
1HHydrogenHydrogen811.00881.648
2.14%
6CCarbonCarbon212.01124.022
0.63%
Total3809.502100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Hauckiet
  • IMA1979-012

In other languages

German
Hauckit · IMA 1979-012
Italian
Hauckite
Chinese
羟碳铁镁锌矾

Classification

Strunz
10th ed.

7.BB.10

  • 7SulfatesClass
  • 7.BSulfates (selenates, etc.) with additional anions, without H2ODivision
  • 7.BBWith medium-sized cationsGroup
  • 7.BB.10HauckiteSpecies
Dana
8th ed.

32.03.04.01

  • 32Compound SulfatesClass
  • 32.03Anhydrous Compound Sulfates containing Hydroxyl or HalogenType
  • 32.03.04— unnamed intermediate level —Group
  • 32.03.04.01HauckiteSpecies
CIM

12.2.20

  • 12Carbonates with other anionsClass
  • 12.2Carbonates with sulphateGroup
  • 12.2.20HauckiteSpecies

Literature, links & citation

Citations
  1. 1980Dunn, Pete J., Peacor, Donald R, Sturman, B. Darko (1980) Hauckite, Fe3+3(Mg,Mn)24Zn18(SO4)4(CO3)2(OH)81 a new mineral from Sterling Hill, New Jersey. American Mineralogist, 65 (1-2) 192-195
  2. 1995Dunn, Pete J. (1995) Franklin and Sterling Hill, New Jersey: The world's most magnificent mineral deposits Vol. 5. The Franklin-Ogdensburg Mineralogical Society.
  3. 2005(2005) Hauckite. Handbook of Mineralogy. Mineralogical Society of America
