Heideite

(Fe,Cr)1.15(Ti,Fe)2S4
IMA status
  • Approved
IMA symbol
Hei
Discovered
1973
IMA approved
1973
Also known as
  • Heideiet
  • IMA1973-062

Where it forms, where it's found

Geological setting

Enstatite achondrite meteorite

Type locality
Bustee meteorite
  1. Gorakhpur
  2. Basti District
  3. Uttar Pradesh
  4. India

26.7500°, 82.7000°

4recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103.5 – 4.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
steel grey
Cleavage
None Observed
Density
3.942 g/cm³

Optical

Pleochroism
Strong

Purple-gray to cream-gray

Optical colour
Creamy white

Crystallography

Crystal system
Monoclinic
Cell parameters
a = 5.97 Å · b = 3.42 Å · c = 11.46 Å
Cell angles
β = 90.1 °
Ratio a:b:c
1 : 0.573 : 1.920
Z
2
Morphology

Anhedral grains to 100 microns

Comment

Space Group: I2/m

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
26FeIronIron3.1555.845175.912
38.27%
16SSulfurSulfur432.060128.240
27.90%
22TiTitaniumTitanium247.86795.734
20.82%
24CrChromiumChromium1.1551.99659.795
13.01%
Total459.681100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Heideiet
  • IMA1973-062

In other languages

German
Heideit
Italian
Heideite

Classification

Strunz
10th ed.

2.DA.15

  • 2Sulfides and SulfosaltsClass
  • 2.DMetal Sulfides, M: S = 3 :4 and 2:3Division
  • 2.DAM:S = 3:4Group
  • 2.DA.15HeideiteSpecies
Dana
8th ed.

02.10.02.03

  • 02SulfidesClass
  • 02.10AmBnXp, with (m+n):p = 3:4Type
  • 02.10.02Wilkmanite GroupGroup
  • 02.10.02.03HeideiteSpecies
CIM

3.8.5

  • 3Sulphides, Selenides, Tellurides, Arsenides and Bismuthides (except the arsenides, antimonides and bismuthides of Cu, Ag and Au, which are included in Section 1)Class
  • 3.8Sulphides etc. of Cr, Mo, W an MnGroup
  • 3.8.5HeideiteSpecies

Literature, links & citation

Citations
  1. 1973Takahashi, T., Yamada, O. (1973) Crystallographic and magnetic properties of the Cd(OH)2 layer structure compound TiS2 containing extra iron. Journal of Solid State Chemistry: 7: 25-30.
  2. 1974Keil, Klaus, Brett, and Robin (1974) Heideite, (Fe,Cr)1+x(Ti,Fe)2S4, a new mineral in the Bustee enstatite achondrite. American Mineralogist, 59 (5-6). 465-470
  3. 2005(2005) Heideite. Handbook of Mineralogy. Mineralogical Society of America
