Hemloite

(Ti,V3+,Fe3+,Al)12As3+2O23(OH)
IMA status
  • Approved
IMA symbol
Hlo
Also known as
  • Hemloiet
  • IMA1987-015

Where it forms, where it's found

Geological setting

Gold deposit.

Type locality
Williams Mine (Page Williams Mine)
  1. Hemlo gold deposit
  2. Bomby Township
  3. Thunder Bay District
  4. Ontario
  5. Canada

48.6953°, -85.9194°

2recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789106.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
Black
Streak
Black
Cleavage
None Observed
Fracture
Irregular/Uneven
Density
4.613 g/cm³

Optical

Pleochroism
Not Visible
Optical colour
Gray
Anisotropism
Weak, dark grey to dark brown rotation-tints.
Bireflectance
None observed.
Tropism
Anisotropic
Reflectance R%
(18.9,20.5) 400, (18.6,19.8) 420, (18.2,19.1) 440, (17.8,18.7) 460, (17.6,18.4) 480, (17.4,18.2) 500, (17.2,18.0) 520, (17.1,17.8) 540, (17.0,17.7) 560, (17.0,17.6) 580, (16.9,17.5) 600, (16.9,17.4) 620, (16.8,17.4) 640, (16.8,17.3) 660, (16.8,17.3) 680, (16.8,17.2) 700
Reflected-light panel
17.4 %anisotropic · dual curve
Specimen sRGB 153, 106, 59
White reference100 % reflector under same lamp
R₁ R₂
Mode
Bireflectance
None observed.
Anisotropism
Weak, dark grey to dark brown rotation-tints.
Reflected colour
Gray

Crystallography

Crystal system
Triclinic
Space group
#2
Cell parameters
a = 7.552 Å · b = 15.842 Å · c = 7.158 Å
Cell angles
α = 78.36 ° · β = 84.97 ° · γ = 86.78 °
Ratio a:b:c
1 : 2.098 : 0.948
Type-locality form

Subhedral to anhedral grains up to 400 x 600 µm in size.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
26FeIronIron1255.845670.140
24.69%
23VVanadiumVanadium1250.942611.304
22.52%
22TiTitaniumTitanium1247.867574.404
21.16%
8OOxygenOxygen2415.999383.976
14.14%
13AlAluminiumAluminium1226.982323.784
11.93%
33AsArsenicArsenic274.922149.844
5.52%
1HHydrogenHydrogen11.0081.008
0.04%
Total2714.460100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Al

Synonyms

  • Hemloiet
  • IMA1987-015

In other languages

German
Hemloit · IMA1987-015
Italian
Hemloite
Portuguese
Hemloíta · IMA1987-015

Classification

Strunz
10th ed.

4.JB.60

  • 4OxidesClass
  • 4.JArsenites, antimonites, bismuthites, sulfites, selenites, tellurites; iodatesDivision
  • 4.JBArsenites, antimonites, bismuthites; with additional anions, without H2OGroup
  • 4.JB.60HemloiteSpecies
Dana
8th ed.

46.02.04.01

  • 46Antimonites and Arsenites Containing Hydroxyl or HalogenClass
  • 46.02MiscellaneousType
  • 46.02.04— unnamed intermediate level —Group
  • 46.02.04.01HemloiteSpecies
CIM

24.3.3

  • 24Antimonates and AntimonitesClass
  • 24.3Antimonates of Ti and PbGroup
  • 24.3.3HemloiteSpecies

Literature, links & citation

Citations
  1. 1989HARRIS, D.C. (1989): The mineralogy and geochemistry of the Hemlo gold deposit, Ontario. Geological Survey of Canada, Economic Geology Report 38.
  2. 1989Harris, D.C., Hoskins, B.F., Grey, I.E., Criddle, A.J. & Stanley, C.J. (1989): Hemloite, (As,Sb)2(Ti,V,Fe,Al)12O23OH: a new mineral from the Hemlo gold deposit, Hemlo, Ontario, and its crystal structure. The Canadian Mineralogist, 27, 427-440.
  3. 2005(2005) Hemloite. Handbook of Mineralogy. Mineralogical Society of America
