Hisingerite

Fe2Si2O5(OH)4 · 2H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Hsg
Discovered
1828
Also known as
  • Canbyite
  • Thraulit
  • Thraulite

Where it forms, where it's found

Geological setting

Weathered zone of a cobalt and rare earth element polymetallic deposit.

Secondary mineral formed by weathering or deuteric alteration of iron bearing silicates or sulfides.

Type locality
Riddarhyttan
  1. Skinnskatteberg
  2. Västmanland County
  3. Sweden

59.8081°, 15.5481°

144recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102.5 – 3/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Greasy · Vitreous
Transparency
Transparent · Translucent
Colour
Black · brownish-black · dark brown · dark green
Streak
Yellowish brown, green
Tenacity
brittle
Cleavage
None Observed
Fracture
Conchoidal · Sub-Conchoidal
Density
2.43 g/cm³

Optical

Optical type
Biaxial (-)
Refractive index
1.66 – 1.73
Surface relief
High
Principal indices
nβ 1.66 – 1.715 · nγ 1.73
Birefringence
0.015
Pleochroism

Frequently isotropic, may have anisotropic areas

Dispersion
r < v
UV response
Not fluorescent in UV
Notes

RI may be 1.5-1.6

Michel-Lévy diagramhighlighted lineδ = 0.0150
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]150 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation150 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Cell parameters
a = 5.40 Å · b = 9.03 Å · c = 14.99 Å
Cell angles
β = 98.32 °
Ratio a:b:c
1 : 1.672 : 2.776
Z
4
Morphology

Massive, compact, may be minutely botryoidal or crudely spherical.

Comment

Amorphous to poorly crystalline

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1115.999175.989
50.01%
26FeIronIron255.845111.690
31.74%
14SiSiliconSilicon228.08556.170
15.96%
1HHydrogenHydrogen81.0088.064
2.29%
Total351.913100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Al
  • Mg
  • Ca

Synonyms

  • Canbyite
  • Thraulit
  • Thraulite

In other languages

French
hisingerite
German
Hisingerit
Spanish
Hisingerita
Italian
Hisingerite
Chinese
水硅铁石

Classification

Strunz
10th ed.

9.ED.10

  • 9SilicatesClass
  • 9.EPhyllosilicatesDivision
  • 9.EDPhyllosilicates with kaolinite layers composed of tetrahedral and octahedral netsGroup
  • 9.ED.10HisingeriteSpecies
Dana
8th ed.

71.01.05.02

  • 71Phyllosilicates Sheets of Six-membered RingsClass
  • 71.01Sheets of 6-membered rings with 1:1 layersType
  • 71.01.05— unnamed intermediate level —Group
  • 71.01.05.02HisingeriteSpecies
CIM

14.19.8

  • 14Silicates not Containing AluminumClass
  • 14.19Silicates of FeGroup
  • 14.19.8HisingeriteSpecies

Literature, links & citation

Citations
  1. 1819Berzelius, J. J. (1819) Nouveau Système de minéralogie. Méquignon-Marvis.
  2. 1828Hisinger, W. (1828) Analyse des mit dem Namen Hisingerit belegten Eisensilicats. Annalen der Physik und Chemie, 13, 505-508.
  3. 1924Hawkins, A.C., Shannon, Earl V. (1924) Canbyite, a new mineral. American Mineralogist, 9 (1). 1-5
  4. 1961Whelan, J. A., Goldich, S. S. (1961) New data for hisingerite and neotocite. American Mineralogist, 46 (11-12) 1412-1423
  5. 1962Lindqvist, Bengt, Jansson, Sven (1962) On the crystal chemistry of hisingerite. American Mineralogist, 47 (11-12) 1356-1362
