Huanghoite-(Ce)

BaCe(CO3)2F
IMA status
  • Approved
IMA symbol
Hho-Ce
Also known as
  • Huanghoiet-(Ce)

Where it forms, where it's found

Geological setting

In hydrothermal deposits, including calcite veins, genetically associated with alkalic grano-syenites and the enclosing hydrothermally altered dolomite.

Type locality
Bayan Obo deposit
  1. Bayan Obo mining district
  2. Baotou City
  3. Inner Mongolia
  4. China

41.7958°, 109.9694°

14recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104.5 – 5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Honey-yellow to yellowish-green
Cleavage

(0001)

Fracture
Irregular/Uneven
Density
4.51 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
1.603 – 1.765
Surface relief
High
Principal indices
nω 1.765 · nε 1.603
Pleochroism
Weak

Greenish yellow shades

Michel-Lévy diagramhighlighted lineδ = 0.1620
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]1620 nm3rd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation1620 nm
Order3rd order
XPL colour

Crystallography

Crystal system
Trigonal
Space group
#99
Cell parameters
a = 5.072(1) Å · c = 38.46(1) Å
Z
6
Morphology

Platy to granular.

Type-locality form

Platy masses up to 10x5x1 cm.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
58CeCeriumCerium1140.116140.116
33.64%
56BaBariumBarium1137.327137.327
32.98%
8OOxygenOxygen615.99995.994
23.05%
6CCarbonCarbon212.01124.022
5.77%
9FFluorineFluorine118.99818.998
4.56%
Total416.457100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Huanghoiet-(Ce)

In other languages

German
Huanghoit-(Ce)
Italian
Huanghoite- · Huanghoite-(Ce)

Classification

Strunz
10th ed.

5.BD.35

  • 5CarbonatesClass
  • 5.BCarbonates with additional anions, without H2ODivision
  • 5.BDWith rare earth elements (REE)Group
  • 5.BD.35Huanghoite-(Ce)Species
Dana
8th ed.

16a.01.04.01

  • 16aAnhydrous Carbonates Containing Hydroxyl or HalogenClass
  • 16a.01(AB)(XO3)ZqType
  • 16a.01.04— unnamed intermediate level —Group
  • 16a.01.04.01Huanghoite-(Ce)Species
CIM

12.1.19

  • 12Carbonates with other anionsClass
  • 12.1Carbonates with halidesGroup
  • 12.1.19Huanghoite-(Ce)Species

Group, growth & confusion

In the same group
4 members
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1961Semenov, E.I., Chang P.-S. (1961) Huanghoite, a new rare-earth mineral. Scientia Sinica: 10(8): 1007-1011 (in Russian).
  2. 1962Chang, P.-S. (1962) Huanghoite and the series bastnaesite - β-BaCO3. Scientia Sinica: 11: 251-258.
  3. 1963Fleischer, M. (1963) New mineral Names. American Mineralogist, 48 (9-10) 1178-1184
  4. 1987Nickel, Ernest H., Mandarino, Joseph A. (1987) Procedures involving the IMA Commission on New Minerals and Mineral Names and guidelines on mineral nomenclature. American Mineralogist, 72 (9-10) 1031-1042
  5. 1993Jambor, John L., Puziewicz, Jacek (1993) New Mineral Names. American Mineralogist, 78 (9-10) 1108-1112
