Ianbruceite

Zn2(AsO4)(OH)(H2O) · 2H2O
IMA status
  • Approved
IMA symbol
Ibc
IMA approved
2011
Also known as
  • Ianbruceiet
  • IMA2011-049
  • Mineral GS17 (of Gebhard)
  • +1 more

Where it forms, where it's found

Geological setting

‘Zinc Pocket’ on the 44 level of Tsumeb mine

Type locality
Tsumeb Mine (Ongopolo Mine)
  1. Tsumeb
  2. Oshikoto Region
  3. Namibia

-19.2270°, 17.7276°

5recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789101/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Sky blue to very pale blue · white · colourless
Streak
white
Tenacity
flexible
Cleavage
Perfect

parallel to (100)

deforms plastically

Density
3.197 g/cm³

Optical

Optical type
Biaxial · 2V measured = 18° · 2V calc = 20°
Refractive index
1.601 – 1.662
Surface relief
Moderate
Principal indices
nα 1.601 · nβ 1.660 · nγ 1.662
Pleochroism
Non-pleochroic
Dispersion
r < v, weak
Extinction
X ∧ a = 12.0º (in β obtuse); Y = b; Z ∧ c = 4.7º (in β obtuse).
UV response
none
Michel-Lévy diagramhighlighted lineδ = 0.0610
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]610 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation610 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P1 21/c 1
Cell parameters
a = 11.793(2) Å · b = 9.1138(14) Å · c = 6.8265(10) Å
Cell angles
β = 103.859(9) °
Ratio a:b:c
1 : 0.773 : 0.579
Z
4
Type-locality form

Thin flakes and tapered platy crystals up to 80 μm long

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
30ZnZincZinc265.380130.760
38.38%
8OOxygenOxygen815.999127.992
37.56%
33AsArsenicArsenic174.92274.922
21.99%
1HHydrogenHydrogen71.0087.056
2.07%
Total340.730100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Ianbruceiet
  • IMA2011-049
  • Mineral GS17 (of Gebhard)
  • Unnamed (Zn Arsenate)

In other languages

French
Ianbrucéite
German
Ianbruceit · IMA 2011-049
Italian
ianbruceite

Classification

Strunz
10th ed.

8.DC

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.DPhosphates, etc. with additional anions, with H2ODivision
  • 8.DCWith only medium-sized cations, (OH, etc.):RO4 = 1:1 and < 2:1Group
  • 8.DCIanbruceiteSpecies
Dana
8th ed.

42.06.11

  • 42Hydrated Phosphates, Etc.containing Hydroxyl or HalogenClass
  • 42.06A2(XO4)Zq·xH2OType
  • 42.06.11— unnamed intermediate level —Group
  • 42.06.11IanbruceiteSpecies

Literature, links & citation

Citations
  1. 1999Gebhard, Georg (1999) Tsumeb Vol. 2 - A Unique Mineral Locality - Tsumeb. GG Publishing. p.1-328.
  2. 2009Blaß, G., Kruijen, F., Seyb, R. (2009) Neues von der Tsumeb Mine. Mineralien-Welt, 20 (5) 60-65
  3. 2009Möhn, G.; Frohwein, J.; Blaß, G. (2009) Neue Mineralfunde von der Grube Friedrichssegen bei Bad Ems. Lapis, 34 (5). 35-40; 58
  4. 2011Williams, P. A., Hatert, F., Pasero, M., Mills, S. J. (2011) New minerals and nomenclature modifications approved in 2011, CNMNC Newsletter No. 10. Mineralogical Magazine, 75 (5) 2549-2561 doi:10.1180/minmag.2011.075.5.2549 DOI: 10.1180/minmag.2011.075.5.2549
  5. 2012Cooper, M. A., Abdu, Y. A., Ball, N. A., Hawthorne, F. C., Back, M. E., Tait, K. T., Schlüter, J., Malcherek, T., Pohl, D., Gebhard, G. (2012) Ianbruceite, ideally [Zn2(OH)(H2O)(AsO4)](H2O)2, a new arsenate mineral from the Tsumeb mine, Otjikoto (Oshikoto) region, Namibia: description and crystal structure. Mineralogical Magazine, 76 (5) 1119-1131 doi:10.1180/minmag.2012.076.5.05 DOI: 10.1180/minmag.2012.076.5.05
