Ianthinite

U4+2(UO2)4O6(OH)4 · 9H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Ian
Discovered
1926
Also known as
  • Ianthiniet
  • Janthiniet
  • Janthinit
  • +8 more

Where it forms, where it's found

Type locality
Shinkolobwe Mine
  1. Shinkolobwe
  2. Kambove Territory
  3. Haut-Katanga
  4. DR Congo

-11.0486°, 26.5508°

32recorded occurrences
Source · OpenStreetMap

Radioactivity

Physical

Hardness
123456789102 – 3/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Sub-metallic
Transparency
Transparent · Translucent
Colour
Violet-black · dark violet in transmitted light

on exposure to air, turns violet-brown, pale brown, then greenish yellow or yellow;

Streak
Brown, violet
Tenacity
flexible
Cleavage
Perfect

Perfect on (001); (100), good.

Fracture
Conchoidal
Density
5.16 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 58° · 2V calc = 30°
Refractive index
1.674 – 1.92
Surface relief
High
Principal indices
nα 1.674 · nβ 1.90 · nγ 1.92
Pleochroism
Strong

X = c = colourless Y = b = violet Z = a = dark violet

Dispersion
r > v perceptible
Luminescence
None
Michel-Lévy diagramhighlighted lineδ = 0.2460
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]2460 nm5th order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation2460 nm
Order5th order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
#19
Cell parameters
a = 11.52(5) Å · b = 7.15(2) Å · c = 30.3(1) Å
Ratio a:b:c
1 : 0.621 : 2.630
Z
4
Morphology

Tiny rectangular plates (001) elongated [010]. Also prismatic [010], or thick tabular (001).

Type-locality form

Acicular crystals

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
92UUraniumUranium6238.0291428.174
75.87%
8OOxygenOxygen2715.999431.973
22.95%
1HHydrogenHydrogen221.00822.176
1.18%
Total1882.323100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Ianthiniet
  • Janthiniet
  • Janthinit
  • Lanthinit
  • Lanthinita
  • Lanthinite
  • Lanthinite (of Schoep)
  • Lanthit
  • Lanthita
  • Lanthite
  • Lianthinit

In other languages

German
Ianthinit
Spanish
Ianthinita
Italian
Ianthinite
Portuguese
Iantinita · iantinite

Classification

Strunz
10th ed.

4.GA.10

  • 4OxidesClass
  • 4.GUranyl HydroxidesDivision
  • 4.GAWithout additional cationsGroup
  • 4.GA.10IanthiniteSpecies
Dana
8th ed.

05.06.01.01

  • 05Oxides Containing Uranium or ThoriumClass
  • 05.06AX6O17·xH2OType
  • 05.06.01— unnamed intermediate level —Group
  • 05.06.01.01IanthiniteSpecies
CIM

7.16.7

  • 7Oxides and HydroxidesClass
  • 7.16Oxides of UGroup
  • 7.16.7IanthiniteSpecies

Group, growth & confusion

Often grow together
2 minerals

Literature, links & citation

Citations
  1. 1926Billiet, Valère (1926) Détermination des indices de réfraction de la becquerélite, de la curite, de la kasolite, de la fourmariérite, de la parsonsite, de la dumontite, et de l'ianthinite. Bulletin de la Société française de Minéralogie, 49 (3). 136-140 doi:10.3406/bulmi.1926.4309DOI: 10.3406/bulmi.1926.4309
  2. 1926Schoep, A. (1926) Over janthiniet, een nieuw uranium mineraal uit Katanga. Natuurwetenschappelijk Tijdschrift: 7: 97-99.
  3. 1927Foshag, W.F. (1927) New Mineral Names. American Mineralogist, 12 (9). 355-356
  4. 1927Schoep (1927), Soc. géol. Belgique, Ann.: 49: B310.
  5. 1934Palache, Charles (1934) Crystallography of the uranium oxides. American Mineralogist, 19 (7) 309-315
