Ice

H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Ice
Also known as

Where it forms, where it's found

48recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789101.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Colourless to white · pale blue to greenish blue in thick layers
Streak
White
Tenacity
brittle
Fracture
Conchoidal
Density
0.9167 g/cm³

Optical

Optical type
Uniaxial (+)
Refractive index
1.30907 – 1.31052
Surface relief
Low
Principal indices
nω 1.30907 · nε 1.31052
Michel-Lévy diagramhighlighted lineδ = 0.0014
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]14 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation14 nm
Order1st order
XPL colour

Crystallography

Crystal system
Hexagonal
Space group
P63/mmc
Cell parameters
a = 4.498 Å · c = 7.338 Å
Z
4
Morphology

Usually as snow crystals, in complex six-rayed stellate forms of great variety, flattened (0001). Delicate skeletal forms or hopper-shaped prisms as hoar frost. Lathlike crystals, greatly elongated at times, by crystallization on the surface of water.

Twinning

Twin plane (α): (0001), and (b): (0001).

Translation gliding
(0001)
Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen115.99915.999
88.81%
1HHydrogenHydrogen21.0082.016
11.19%
Total18.015100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Gelo
  • Ghiaccio
  • Glace
  • IJs
  • Is

In other languages

German
Eis
Russian
Группа льда · лёд

Classification

Strunz
10th ed.

4.AA.05

  • 4OxidesClass
  • 4.AMetal: Oxygen = 2:1 and 1:1Division
  • 4.AACation:Anion (M:O) = 2:1 (and 1.8:1)Group
  • 4.AA.05IceSpecies
Dana
8th ed.

04.01.02.01

  • 04Simple OxidesClass
  • 04.01A2XType
  • 04.01.02— unnamed intermediate level —Group
  • 04.01.02.01IceSpecies
CIM

7.1.1

  • 7Oxides and HydroxidesClass
  • 7.1Oxides of hydrogenGroup
  • 7.1.1IceSpecies

Group, growth & confusion

Often grow together
1 mineral
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. www.its.caltech.edu
  2. Gudkovskikh, S.V. & Kirov, M.V. (2023): Ice structures assembled from cubic water clusters of D2d and S4 symmetry. Acta Crystallographica, A79, (in press).
  3. 1611Kepler, J. (1611) Strena seu de nive sexangula. ["New Year's gift or about the hexangular snow", in Latin, probably the first description of the hexagonal symmetry of snow crystals]
  4. 1893Hellmann, G. (1893) Schneekrystalle. Verlag von Rudolf Mückenberger, Berlin, 66 pp. [http://gdz.sub.uni-goettingen.de/no_cache/dms/load/img/?IDDOC=320734]
  5. 1916Dobrowolski (1916) Ark. Kemi: 6(7).
