Iltisite

HgAgSCl
IMA status
  • Approved
IMA symbol
Iti
Discovered
1995
Also known as
  • Iltisiet
  • IMA1994-031

Where it forms, where it's found

Type locality
Cap Garonne Mine
  1. Le Pradet
  2. Toulon
  3. Var
  4. Provence-Alpes-Côte d'Azur
  5. France

43.0814°, 6.0322°

3recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Lustre
Adamantine
Transparency
Translucent
Colour
Red to red-brown
Streak
Red
Tenacity
brittle
Cleavage
Perfect

(001)

Fracture
Irregular/Uneven
Density
6.59 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
2.1 – 2.3
Surface relief
Very high
Principal indices
nω 2.3 · nε 2.1
Pleochroism
Visible

O = red, E = brownish red.

UV response
Not fluorescent.
Michel-Lévy diagramhighlighted lineδ = 0.2000
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]2000 nm4th order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation2000 nm
Order4th order
XPL colour

Crystallography

Crystal system
Hexagonal
Cell parameters
a = 8.234(4) Å · c = 19.38(1) Å
Z
12
Morphology

Hexagonal crystals, flattened on (001) and showing (001) and (101).

Type-locality form

Isolated, hexagonal crystals to 0.02 mm in diameter.

Comment

Space group P62, P64, P6222 or P6422.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
80HgMercuryMercury1200.592200.592
53.35%
47AgSilverSilver1107.868107.868
28.69%
17ClChlorineChlorine135.45035.450
9.43%
16SSulfurSulfur132.06032.060
8.53%
Total375.970100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Iltisiet
  • IMA1994-031

In other languages

German
Iltisit · IMA 1994-031
Italian
Iltisite
Chinese
氯硫溴银汞矿

Classification

Strunz
10th ed.

2.FC.20b

  • 2Sulfides and SulfosaltsClass
  • 2.FSulfides of arsenic, alkalies; sulfides with halide, oxide, hydroxide, H2ODivision
  • 2.FCWith Cl, Br, I (halide-sulfides)Group
  • 2.FC.20bIltisiteSpecies

Group, growth & confusion

Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1997Sarp, H., Sanz-Gysler, J., Perroud, P. (1997) L'iltisite, HgSAg(Cl,Br), un nouveau minéral de la mine de Cap Garonne, Var (France), polymorphe de la capgaronnite. Archives des Sciences, Genève, 50 (1) 1-5
  2. 1998Mandarino, Joseph A. (1998) Abstracts of New Mineral Descriptions. The Mineralogical Record, 29 (3) 233-237
  3. 1998Jambor, John L., Roberts, Andrew C. (1998) New mineral names. American Mineralogist, 83 (3-4) 400-403
