Jadarite

LiNaB3SiO7(OH)
IMA status
  • Approved
IMA symbol
Jad
Discovered
2006
IMA approved
2006
Also known as
  • IMA2006-036

Where it forms, where it's found

Geological setting

A sequence of oil-shales, dolomicrites, pyroclastics, and evaporites which formed during the development of an intramontane lacustrine sedimentary basin.

Type locality
Jadar lithium deposit
  1. Jadar valley
  2. Loznica
  3. Mačva District
  4. Central Serbia
  5. Serbia

44.5333°, 19.3000°

1recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104 – 5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent · Opaque
Colour
White
Streak
White
Tenacity
brittle
Fracture
Irregular/Uneven · Conchoidal
Density
2.45 g/cm³

Optical

Optical type
Biaxial
Refractive index
1.536 – 1.563
Surface relief
Moderate
Principal indices
nα 1.536 · nγ 1.563
Pleochroism
Non-pleochroic
Extinction
Does not show parallel extinction. Extinction at 8° either side of the twin plane.
Optical colour
Dark gray
Anisotropism
Any possible anisotropy masked by abundant internal re-flections..
Bireflectance
Weak
Internal reflections
Abundant, white
UV response
Weak pink-orange (LW & SW UV).
Michel-Lévy diagramhighlighted lineδ = 0.0270
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]270 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation270 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Cell parameters
a = 6.816(2) Å · b = 13.789(2) Å · c = 6.758(2) Å
Cell angles
β = 111.08(2) °
Ratio a:b:c
1 : 2.023 : 0.991
Unit cell volume
592.8 ų
Z
4
Morphology

Massive aggregates, several meters thick. Individual subhedral (tabular, elongate) to anhedral crystals rarely exceed 5 - 10 μm in size. Platy habit.

Twinning

Exhibited by transmitted light in plates and grains in some crystallites.

Type-locality form

Massive white aggregates, several meters thick from a drill core.

Comment

P21/c setting given in Whitfield et al. (2007)

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen815.999127.992
58.32%
5BBoronBoron310.81032.430
14.78%
14SiSiliconSilicon128.08528.085
12.80%
11NaSodiumSodium122.99022.990
10.48%
3LiLithiumLithium16.9406.940
3.16%
1HHydrogenHydrogen11.0081.008
0.46%
Total219.445100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA2006-036

In other languages

French
Jadarite
German
IMA 2006-036 · Jadarit
Spanish
Jadarita
Italian
Jadarite
Portuguese
jadarita
Japanese
ジャダライト
Russian
Ядарит

Classification

Strunz
10th ed.

9.AJ.40

  • 9SilicatesClass
  • 9.ANesosilicatesDivision
  • 9.AJNesosilicates with BO3 triangles and/or B[4], Be[4] tetrahedra, cornersharing with SiO4Group
  • 9.AJ.40JadariteSpecies

Literature, links & citation

Citations
  1. New Minerals Approved in 2006: November 2006 - IMA-CNMNC website
  2. 2007news.bbc.co.uk (n.d.) http://news.bbc.co.uk/1/hi/sci/tech/6584229.stm
  3. 2007Whitfield, Pamela S., Le Page, Yvon, Grice, Joel D., Stanley, Chris J., Jones, Gary C., Rumsey, Michael S., Blake, Chris, Roberts, Andrew C., Stirling, John A. R., Carpenter, Gordon J. C. (2007) LiNaSiB3O7(OH) – novel structure of the new borosilicate mineral jadarite determined from laboratory powder diffraction data. Acta Crystallographica Section B Structural Science, 63 (3) 396-401 doi:10.1107/s0108768107010130DOI: 10.1107/s0108768107010130
  4. 2007Stanley, Christopher J., Jones, Gary C., Rumsey, Michael S., Blake, Christopher, Roberts, Andrew C., Stirling, John A.R., Carpenter, Graham J.C., Whitfield, Pamela S., Grice, Joel D., Lepage, Yvon (2007) Jadarite, LiNaSiB3O7(OH), a new mineral species from the Jadar Basin, Serbia. European Journal of Mineralogy, 19 (4) 575-580 doi:10.1127/0935-1221/2007/0019-1741 DOI: 10.1127/0935-1221/2007/0019-1741
  5. 2013(2013) Jadarite. Handbook of Mineralogy. Mineralogical Society of America
