Jaffeite

Ca6Si2O7(OH)6
IMA status
  • Approved
IMA symbol
Jaf
IMA approved
1987
Also known as
  • IMA1987-056
  • Jaffeiet

Where it forms, where it's found

Geological setting

Low-grade metamorphic rocks.

Type locality
Kombat Mine
  1. Kombat
  2. Otavi Constituency
  3. Otjozondjupa Region
  4. Namibia

-19.7081°, 17.7033°

1recorded occurrences
Source · OpenStreetMap

Physical

Transparency
Transparent
Colour
Colorless
Streak
White
Tenacity
brittle
Cleavage
Imperfect/Fair

(1010)

Fracture
Conchoidal
Density
2.65 g/cm³

Optical

Optical type
Uniaxial (+)
Refractive index
1.596 – 1.604
Surface relief
Moderate
Principal indices
nω 1.596 · nε 1.604
Michel-Lévy diagramhighlighted lineδ = 0.0080
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]80 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation80 nm
Order1st order
XPL colour

Crystallography

Crystal system
Trigonal
Space group
#79
Cell parameters
a = 10.026(5) Å · c = 7.482(4) Å
Z
2
Morphology

The only forms observed are (001) and (100).

Type-locality form

Euhedral to subhedral crystals elongated parallel to [0001], to 0.4 mm.

Comment

space group by analogy to synthetic

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
20CaCalciumCalcium640.078240.468
47.09%
8OOxygenOxygen1315.999207.987
40.73%
14SiSiliconSilicon228.08556.170
11.00%
1HHydrogenHydrogen61.0086.048
1.18%
Total510.673100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1987-056
  • Jaffeiet

In other languages

German
IMA 1987-056 · Jaffeit
Italian
Jaffeite
Portuguese
IMA1987-056 · Jaffeíta
Chinese
佳羟硅钙石
Arabic
جافيت

Classification

Strunz
10th ed.

9.BE.12

  • 9SilicatesClass
  • 9.BSorosilicatesDivision
  • 9.BESi2O7 groups, with additional anions; cations in octahedral [6] and greater coordinationGroup
  • 9.BE.12JaffeiteSpecies
Dana
8th ed.

55.03.02.01

  • 55Sorosilicates Si2o7 Groups, Generally with No Additional AnionsClass
  • 55.03Si2O7 Groups, Generally with no Additional Anions with cations in [7] coordinationType
  • 55.03.02— unnamed intermediate level —Group
  • 55.03.02.01JaffeiteSpecies
CIM

14.5.15

  • 14Silicates not Containing AluminumClass
  • 14.5Silicates of CaGroup
  • 14.5.15JaffeiteSpecies

Literature, links & citation

Citations
  1. 1988Peacor, Donald R., Sarp, Halil, Dunn, Pete J., Innes, John, Nelen, Joseph A. (1988) Defernite from the Kombat mine, Namibia: A second occurrence, structure refinement, and crystal chemistry. American Mineralogist, 73 (7-8) 888-893
  2. 1989Sarp, H., Peacor, Donald R. (1989) Jaffeite, a new hydrated calcium silicate from the Kombat mine, Namibia. American Mineralogist, 74 (9-10) 1203-1206
  3. 1991Dunn, Pete J. (1991) Rare Minerals of the Kombat Mine. The Mineralogical Record, 22 (6) 421-425
  4. 1993Yamnova, N.A., Sarp, K., Egorov-Tismenko, Y.K., Pushcharovskii, D.Y. (1993) Crystal structure of jaffeite. Crystallography Reports, 38, 464-467.
  5. 2001(2001) Jaffeite. Handbook of Mineralogy. Mineralogical Society of America
