Jagowerite

BaAl2(PO4)2(OH)2
IMA status
  • Approved
IMA symbol
Jgw
Discovered
1973
IMA approved
1973
Also known as
  • IMA1973-001
  • Jagoweriet

Where it forms, where it's found

Type locality
Hess River
  1. Mayo mining district
  2. Yukon
  3. Canada

63.5833°, -132.8000°

2recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Light green
Cleavage
Distinct/Good

(100) good, (011) good, (011) fair

Density
4.01 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 80°
Refractive index
1.672 – 1.71
Surface relief
High
Principal indices
nα 1.672 · nβ 1.693 · nγ 1.71
Dispersion
relatively strong
UV response
Fluoresces greenish-white under along-wave ultraviolet radiation.
Michel-Lévy diagramhighlighted lineδ = 0.0380
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]380 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation380 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Cell parameters
a = 6.049(2) Å · b = 6.964(3) Å · c = 4.971(2) Å
Cell angles
α = 116.51(4) ° · β = 86.06(4) ° · γ = 112.59(3) °
Ratio a:b:c
1 : 1.151 : 0.822
Z
1
Type-locality form

Crystalline masses up to 2.5 cm across in quartz veins.

Comment

Point Group: _1 or 1; Space Group: P_1 or P1.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1015.999159.990
38.53%
56BaBariumBarium1137.327137.327
33.07%
15PPhosphorusPhosphorus230.97461.948
14.92%
13AlAluminiumAluminium226.98253.964
13.00%
1HHydrogenHydrogen21.0082.016
0.48%
Total415.245100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1973-001
  • Jagoweriet

In other languages

German
IMA 1973-001 · Jagowerit
Italian
Jagowerite

Classification

Strunz
10th ed.

8.BH.55

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.BPhosphates, etc., with additional anions, without H2ODivision
  • 8.BHWith medium-sized and large cations, (OH,etc.):RO4 = 1:1Group
  • 8.BH.55JagoweriteSpecies
Dana
8th ed.

41.10.03.01

  • 41Anhydrous Phosphates, Etc.containing Hydroxyl or HalogenClass
  • 41.10(AB)3(XO4)2ZqType
  • 41.10.03— unnamed intermediate level —Group
  • 41.10.03.01JagoweriteSpecies
CIM

19.5.9

  • 19PhosphatesClass
  • 19.5Phosphates of Sr and BaGroup
  • 19.5.9JagoweriteSpecies

Literature, links & citation

Citations
  1. 1973Meagher, E.P., Coates, M.E., Aho, A.E. (1973) Jagowerite: a new barium phosphate mineral from the Yukon Territory. The Canadian Mineralogist, 12 (2) 135-136
  2. 1974Meagher, E. P., Gibbons, C. S., Trotter, J. (1974) The crystal structure of jagowerite: BaAl2P2O8(OH)2. American Mineralogist, 59 (3-4) 291-295
  3. 2005(2005) Jagowerite. Handbook of Mineralogy. Mineralogical Society of America
