Jarlite

Na2(Sr,Na)14(Mg,◻)2Al12F64(OH)4
IMA status
  • Approved
  • Grandfathered
IMA symbol
Jar
Discovered
1933
Also known as
  • Jarliet

Where it forms, where it's found

Geological setting

Pegmatitic cryolite deposit in granite.

Type locality
Ivigtut Mine
  1. Ivigtut stock
  2. Arsuk Fjord
  3. Sermersooq
  4. Greenland

61.2061°, -48.1756°

2recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104 – 4.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Colourless · white · greyish · colourless in transmitted light.
Streak
White
Fracture
Irregular/Uneven
Density
3.78 g/cm³

Optical

Optical type
Biaxial (+/-) · 2V measured = 90° · 2V calc = 80°
Refractive index
1.429 – 1.436
Surface relief
Low
Principal indices
nα 1.429 · nβ 1.433 · nγ 1.436
Dispersion
none
Michel-Lévy diagramhighlighted lineδ = 0.0070
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]70 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation70 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Cell parameters
a = 15.942 Å · b = 10.821 Å · c = 7.241 Å
Cell angles
β = 101.86 °
Ratio a:b:c
1 : 0.679 : 0.454
Morphology

Crystals minute and tabular (100) and elongated [010]. Commonly grouped in fan-like or spherulitic aggregates. Massive; radial columnar structure at times.

Type-locality form

Drusy crystals in cavities with thomsenolite in partially dissolved cryolite.

Comment

SG C2/m.

Crystal structure

Chemical composition

Impurities
  • Ca

Synonyms

  • Jarliet

In other languages

German
Jarlit
Italian
Jarlite
Russian
Ярлит
Arabic
جارليت

Classification

Strunz
10th ed.

3.CC.20

  • 3HalidesClass
  • 3.CComplex halidesDivision
  • 3.CCSoro-aluminofluoridesGroup
  • 3.CC.20JarliteSpecies
Dana
8th ed.

11.06.10.01

  • 11Halide ComplexesClass
  • 11.06Aluminofluorides - Isolated OctahedraType
  • 11.06.10Jarlite GroupGroup
  • 11.06.10.01JarliteSpecies
CIM

8.4.12

  • 8Halides - Fluorides, Chlorides, Bromides and Iodides; also Fluoborates and FluosilicatesClass
  • 8.4Halides of the alkaline earths and MgGroup
  • 8.4.12JarliteSpecies

Literature, links & citation

Citations
  1. 1933Bøgvad, R. (1933) New minerals from Ivigtut, Southwest Greenland. Meddelelser om Grønland: 92(8): 2-11.
  2. 1935Foshag, W.F. (1935) New mineral names. American Mineralogist: 20: 137-138.
  3. 1942Brosset (1942) Doctoral dissertation, Stockholm.
  4. 1949Ferguson, R. B. (1949) Observations on some aluminium fluoride minerals. American Mineralogist, 34 (5-6) 383-397
  5. 1951Palache, Charles; Berman, Harry; Frondel, Clifford (1951) The System of Mineralogy (7th ed.) Vol. 2 - Halides, Nitrates, Borates, Carbonates, Sulfates, Phosphates, Arsenates, Tungstates, Molybdates, Etc. John Wiley and Sons.
