Jasmundite

Ca11O2(SiO4)4S
IMA status
  • Approved
IMA symbol
Jas
Discovered
1981
Also known as
  • IMA1981-047
  • Jasmundiet

Where it forms, where it's found

Geological setting

Metamorphosed limestone xenoliths in basalt

Type locality
Ettringer Feld
  1. Ettringen
  2. Vordereifel
  3. Mayen-Koblenz
  4. Rhineland-Palatinate
  5. Germany

50.3458°, 7.2222°

9recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent · Opaque
Colour
Pale to smoky green · also greenish brown
Streak
White
Tenacity
brittle
Cleavage
None Observed
Fracture
Conchoidal · Sub-Conchoidal
Density
3.03 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
1.728 – 1.75
Surface relief
High
Principal indices
nω 1.750 · nε 1.728
Birefringence
0.022
Extinction
Reported optics are also unixial (+) Nω = 1.715 Nε = 1.728 due to Al, Fe, Mg substitution
UV response
Not fluorescent in UV
Michel-Lévy diagramhighlighted lineδ = 0.0220
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]220 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation220 nm
Order1st order
XPL colour

Crystallography

Crystal system
Tetragonal
Space group
I-4m2
Cell parameters
a = 10.461 Å · c = 8.813 Å
Z
2
Morphology

Dominant (110) and (101) forms.

Type-locality form

Irregular grains, up to several millimeters in size and occasionally, as euhedral crystals of isometric habit.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
20CaCalciumCalcium1140.078440.858
50.49%
8OOxygenOxygen1815.999287.982
32.98%
14SiSiliconSilicon428.085112.340
12.86%
16SSulfurSulfur132.06032.060
3.67%
Total873.240100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Al
  • Fe
  • Mg

Synonyms

  • IMA1981-047
  • Jasmundiet

In other languages

German
IMA 1981-047 · Jasmundit
Italian
Jasmundite
Chinese
约硫硅钙石

Classification

Strunz
10th ed.

9.AG.70

  • 9SilicatesClass
  • 9.ANesosilicatesDivision
  • 9.AGNesosilicates with additional anions; cations in > [6] +- [6] coordinationGroup
  • 9.AG.70JasmunditeSpecies
Dana
8th ed.

52.04.07.04

  • 52Nesosilicates Insular Sio4 Groups and O, Oh, F, H2oClass
  • 52.04Insular SiO4 Groups and O, OH, F, and H2O with cations in [6] and/or >[6] coordinationType
  • 52.04.07Afwillite and related speciesGroup
  • 52.04.07.04JasmunditeSpecies
CIM

17.9.2

  • 17Silicates Containing other AnionsClass
  • 17.9Silicates with sulphide or sulphiteGroup
  • 17.9.2JasmunditeSpecies

Literature, links & citation

Citations
  1. 1981Dent Glasser, L. S., Lee, C. K. (1981) The structure of jasmundite, Ca22(SiO4)8O4S2. Acta Crystallographica Section B Structural Crystallography and Crystal Chemistry, 37 (4) 803-806 doi:10.1107/s0567740881004366DOI: 10.1107/s0567740881004366
  2. 1983Hentschel, G., Dent Glasser, L. S., Lee, C. K. (1983) Jasmundite, Ca22(SiO4)8O4S2, a new mineral. Neues Jahrbuch für Mineralogie - Monatshefte, 1983. 337-342
  3. 1984Dunn, Pete J., Chao, George Y., Grice, Joel D., Ferraiolo, James A., Fleischer, Michael, Pabst, Adolf, Zilczer, Janet A. (1984) New mineral names. American Mineralogist, 69 (5-6) 565-569
  4. 1986Bikbaou, M.Y. (1986) Crystal chemistry and properties of alinite and jasmundite. 8th International Congress on the Chemistry of Cement: 2: 352-357.
  5. 1989Ilinets, A.M., Bikbau, M.Y., Nudelman, B.I., Bolotina, N.B. (1989) The peculiarities of the atomic-structure of alinite and jasmundite. Kristallografiya: 34: 71-77.
